Pall iCELLis 500+ - Sensors and Actuators Specifications

Page 41 of 48
6.2 Sensors and Actuators Specifications
TAG P&ID
Description
Range
Accuracy
Unit
TT_01
Temperature culture media before fixed-bed T1
0,0 ... 50,0
+/- 0.3
°C
TT_02
Temperature culture media before fixed-bed T2
0,0 ... 50,0
+/- 0.3
°C
TT_03
Temperature pre heater bag 1
0,0 ... 100,0
+/- 1.0
°C
TT_04
Temperature pre heater bag 2
0,0 ... 100,0
+/- 1.0
°C
TT_05
Temperature heating system TCU
0,0 ... 50,0
+/- 1.0
°C
TT_06
Temperature of exhaust heater
0,0 ... 100,0
+/- 2.0
°C
AT_01
pH culture media before fixed-bed Polestar pH1
6.5 ... 8.5
+/- 0.1
1
N/A
AT_02
pH culture media after fixed-bed Polestar pH2
6.5 ... 8.5
+/- 0.1
1
N/A
AT_03 DO culture media before fixed-bed Polestar DO1 0 ... 150
+/- 3.5 between
15 and 75%,
else +/- 7%
%airsat
AT_04 DO culture media after fixed-bed Polestar DO2 0 ... 150
+/- 3.5 between
15 and 75%,
else +/- 7%
%airsat
AT_05
Biomass of the fixed-bed in mS/cm
-2,0 ... 40,0
+/- 3.0%
mS/cm
AT_06
Biomass of the fixed-bed in pF/cm
-5 ... 400
+/- 3.0%
pF/cm
FT_01
CO
2
flow transmitter
0,00 ... 1,50
+/- 0.1
NL/min
FT_02
N
2
flow transmitter
0,00 ... 1,50
+/- 0.1
NL/min
FT_03
Air flow transmitter
0,00 ... 3,00
+/- 0.1
NL/min
FT_04
O
2
flow transmitter
0,00 ... 7,00
+/- 0.1
NL/min
PT_01
Pressure double jacket
0,0 ... 300,0
+/- 5.0
mbarg
PT_02
Pressure bioreactor
0,0 ... 100,0
+/- 5.0
mbarg
PT_03
Pressure middle assembly
0 ... 250
+/- 10.0
mbarg
WT_01
Weight base bag
0,00 … 60,0
+/- 0.1
Kg
1
The correct level of accuracy can only be expected at the pH value at which the 1-point calibration is performed.
The greater the distance from the point of calibration, the lower the probability that the accuracy will be within
specification. Therefore, if these bioreactors demonstrate a greater distance, then Pall’s recommendation is that
the bioreactors can only be used under mitigation actions, specifically manual pH control. Our dedicated
Application team can give you support for these mitigation actions.
