Screen displays
Camera mode and VCR mode
1Counter display
Each time the COUNTER button is pressed,
the data is selected in the sequence given
below.
COUNTER:
Counter value
M COUNTER:
Counter value in the memory stop mode
TC:
Time code value
“TC2” is displayed when the time code
value could not be read out properly from
the tape.
During operation in the drop frame mode, a
colon (:) appears between the seconds and
frames.
UB:
User’s bit value
“UB
2” is displayed when the user’s bit
value could not be read out properly from
the tape.
FR:
Information on the frame rate used when
shooting
FR 60I : Standard (60i interlace) mode
(60 fields per sec.)
FR 30P : 30P progressive mode
(30 frames per sec.)
FR 24P : 24P progressive mode
(24 frames per sec.)
FR 24PA: 24P advance mode
(24 frames per sec.)
In the FR 24P and FR 24PA modes, the
sequence information used for frame
conversion is displayed at the last digits.
2AWB/ABB operation status display
The operation statuses of the auto white
balance and auto black balance are displayed
here.
3AWB error display
LOW LIGHT:
This appears when the luminance is too
low during the auto white balance
adjustment.
4Recording time mode display (SP or LP)
5Squeeze recording display
This appears when SQUEEZE has been
selected (see page 42) as the ASPECT
CONV item setting on the setting menu
CAMERA SETUP screen and squeeze
recording is being performed or when
squeeze recorded images are being played
back.
6Setting selection display
The selected setting appears here when a
switch has been selected or a button has
been pressed to select a setting.
7Auto iris control status display
STD : Standard auto iris control
SPOT : Auto iris control for spotlight
BACK : Auto iris control for backlight
compensation
