E-5
Precautions for when Connecting the System
(Continued)
z Operation becomes possible on the
camera recorder when the power of the
unit is turned off, even if the unit is
connected.
z The unit can be used in combination with
the following camera recorders and base
station.
AJ-HPX3700G, AJ-HPX3000G,
AJ-HPX2700G, AJ-HPX2000/2100,
AG-HPX500/502,
AG-HPX300/301/302/304, AJ-HDX900P/E
System connections
The unit is connected to a camera recorder or base station for use.
<Notes>
z Video is not output from the VIDEO OUTPUT connector of the unit when it is connected to
the base station, and the system mode is set to 1080/23.98PsF, 1080/24PsF, 1080/60i or
720/60p.
z When the unit is used in combination with a base station and a camera adaptor
(AG-CA300G; optional), the included 10-pin cable cannot be used to directly connect the unit
to the camera recorder.
To Next Page
