CQ-C5403U/C5303U
36
Above Specifications comply with EIA standards.
Specifications
Power supply : DC 12 V (11 V – 16 V), test
voltage 14.4 V, negative
ground
Current consumption : Less than 2.2 A (CD mode,
0.5 W 4-channels)
Maximum power output : 50 W x 4 (at 1 kHz)
volume control maximum
Tone/SQ adjustment range : SQ Low/Bass: ± 12 dB (at 60
Hz, 80 Hz, 100 Hz, 200 Hz)
SQ Mid: ± 12 dB (at 500 Hz,
1 kHz, 2 kHz, 3 kHz)
SQ High/Treble: ± 12 dB (at
10 kHz, 12 kHz, 15 kHz,
18 kHz)
Speaker impedance : 4 – 8 Ω
Pre-amp output voltage : 4 V (CD mode, 1 kHz, 0 dB)
Pre-amp output
impedance : 60 Ω
Subwoofer output voltage : 4 V
Subwoofer output impedance : 60 Ω
Pre-amp output voltage : 2.5 V (CD mode, 1 kHz, 0 dB)
Pre-amp output
impedance : 200 Ω
Subwoofer output voltage : 2.5 V
Subwoofer output impedance : 200 Ω
Dimensions (W x H x D) : 178 x 50 x 155 mm
{7” x 1
15
/
16
”x 6
1
/
8
”}
Weight : 1.6 kg
{3 lbs. 8 oz}
CQ-C5303U
CQ-C5403U
General
Frequency range : 87.9 MHz – 107.9 MHz
Usable sensitivity : 10.2 dBf (0.9 µV, 75 Ω)
50 dB quieting sensitivity : 15.2 dBf (1.6 µV, 75 Ω)
Frequency response : 30 Hz – 15 kHz (±3 dB)
Alternate channel selectivity : 75 dB
Stereo separation : 35 dB (1 kHz)
Image rejection ratio : 55 dB
IF rejection ratio : 100 dB
Signal to noise ratio : 62 dB
Frequency range : 530 kHz – 1 710 kHz
Usable sensitivity : 27 dB/µV (22 µV, S/N 20 dB)
Sampling frequency : 8 times oversampling
DA converter : 1 bit DAC System
Pick-up type : Astigma 3-beam
Light source : Semiconductor laser
Wave length : 790 nm
Frequency response : 20 Hz – 20 kHz (±1 dB)
Signal to noise ratio : 96 dB
Total harmonic distortion : 0.01 % (1 kHz)
Wow and flutter : Below measurable limits
Channel separation : 75 dB
CD Player
AM Radio
FM Stereo Radio
Power Output:
18 W RMS x 4 Channels at 4 Ω and ≤ 1% THD+N
Signal to Noise Ratio:
78 dBA (reference: 1 W into 4 Ω)(for CQ-C5403U)
85 dBA (reference: 1 W into 4 Ω)(for CQ-C5303U)
Note:
¡Specifications and design are subject to modification without notice due to improvements.
¡Some figures and illustrations in this manual may be different from your product.
