16
When the charge provided by your battery pack is supplied for only a short period of
time, even after fully charging according to the instructions, it may be time to replace
your battery pack. The battery pack is a consumable item and therefore will require
replacement (CF-VZSU21).
Replacing the Battery Pack
1 Power off your computer ( “Starting Up/Shutting Down”)
Do not shut down using the standby or hibernation mode.
Battery Power
Do not touch the terminals on the battery pack. The battery pack may no longer
function properly if the contacts are dirty or damaged.
The battery pack is not charged when the computer is first purchased. Be sure to
charge it before using it for the first time. When the AC adaptor is connected to
the computer, charging begins automatically.
Use only the specified battery pack (CF-VZSU21) with your computer.
In the standby mode, do not remove/change the battery pack. Removing the
pack in the standby mode will erase your data and may damage the computer.
CAUTION
Main battery slot
Second battery slot
Be sure to insert the battery pack as illustrated.
Be sure the battery pack is properly connected to the connector.
For an improperly attached cover, your battery pack may fall out while
you are carrying around your computer.
Be sure the tab does not get caught when closing the cover.
CAUTION
CAUTION
2 Taking out the battery pack
Turn over the computer, then unlock the cover by sliding the latch to the right.
Slide the latch down, and then without releasing it, open the cover as illus-
trated.
Pull the tab on the battery pack and remove it from the computer.
Close the cover, then lock it by sliding the latch to the left.
Latch
Bottom
Inserting a battery pack
Firmly attach the battery pack to the connector as illustrated.
Tab
Battery Pack
Tab
To Next Page
