Dimensions Height inch (mm) 10 - 31/32 (279) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 27 - 17/32 (699)
Depth inch (mm) 7 - 27/32 (199) 11 - 7/32 (285)
Net Weight lb (kg) 20 (9.0) 86 (39.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 1,100
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 30% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 33.3 - 31.0 71.0 - 67.0
Rate Output W 15 25
Fan Speed Low rpm Cooling; 890 - 835 —
Heating; 890 - 835
Medium rpm Cooling; 1,125 - 1,075 —
Heating; 1,125 - 1,075
High rpm Cooling; 1,260 - 1,235 —
Heating; 1,340 - 1,330
SuperHigh rpm Cooling; 1,340 - 1,330 —
Heating; 1,340 - 1,330
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 14 1 × 20
FPI 21 18
Size (W × H × L) mm 614 × 294 × 25.4 782.9 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(410)
Refrigerant (R-22) g (oz) — 990 (34.9)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 1,100, Heating; 470
Flow Rate l/min — Cooling; 6.0, Heating; 13.4
Inner Diameter mm — Cooling; 1.3, Heating; 1.5
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 1.5 µF, 400VAC
•
Specifications are subject to change without notice for further improvement.
11
CS-A75KE CU-A75KE / CS-A95KE CU-A95KE / CS-A125KE CU-A125KE
