20 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-A125KE>
NO. DESCRIPTION & NAME Q’TY CU-A125KE REMARKS
1 CHASSY ASS’Y 1 CWD50K659A
2 FAN MOTOR BRACKET 1 CWD54254
3 SCREW - FAN MOTOR BRACKET 2 CWH55189
4 FAN MOTOR 1 CWA95381 0
5 SCREW - FAN MOTOR MOUNT 4 CWH55406
6 COMPRESSOR 1 2KS224D5CA02 0
7 ANTI - VIBRATION BUSHING 3 CWH50055
8 NUT - COMPRESSOR MOUNT 3 CWH4582065
9 PACKING - COMPRESSOR MOUNTE 1 CWB81047
10 CONDENSER 1 CWB32C336
11 4-WAY VALVE 1 CWB00003 0
12 TUBE ASS’Y (CHECK VALVE / CAPILLARY) 1 CWT01C652
13 HOLDER COUPLING ASS’Y 1 CWH35177
14 3-WAY VALVE 1 CWB01480 0
15 2-WAY VALVE 1 CWB02308 0
16 STRAINER 1 CWB11025
17 V - COIL COMPLETE 1 CWA43C2008 0
18 SOUND PROOF BOARD 1 CWH15288
19 SOUND PROOF MATERIAL 1 CWG302075
20 WIRE NET 1 CWD04197A
21 AIR GUIDER PROPELLER FAN 1 CWD31138
22 OVERLOAD PROPECTOR 1 CWA12360 0
23 HOLDER - O.L.P. 1 CWH7041200
24 TERMINAL COVER 1 CWH171011
25 NUT - TERMINAL COVER 1 CWH7080300
26 TEMPERATURE RELAY 1 CWA14C1001 0
27 CONTROL BOARD 1 CWH10972
28 TERMINAL BOARD ASS’Y 1 CWA28K216
29 ELECTROLYTIC CAPACITOR 1 CWA32C045 0
30 TERMINAL BOARD ASS’Y 1 CWA4711012
31 CAPACITOR - COMPRESSOR 1 CWA31647
(30µF, 370V)
0
32 HOLDER CAPACITOR 1 CWH30057
33 CAPACITOR - FAN MOTOR 1 CWA31604
(1.5µF, 400V)
0
34 ELECTROMAGNETIC SWITCH 1 CWA00111 0
35 ELECTROMAGNETIC SWITCH 1 CWA00059 0
36 ELECTROLYTIC CAPACITOR 1 CWA32C067 0
37 PROPELLER FAN ASS’Y 1 CWH00K087
38 NUT - PROPELLER FAN 1 CWH56053
39 CABINET SIDE PLATE (RIGHT) 1 CWE04217A
40 CABINET SIDE PLATE ( LEFT) 1 CWE04220A
41 CABINET FRONT PLATE 1 CWE06K104A
42 HANDLE 1 CWE16037C
43 CONTROL BOARD COVER 1 CWH13461
44 PLATE FOR CONTROL BOARD COVER 1 CWD91258
45 CABINET TOP PLATE 1 CWE03K035A
46 L - TUBE 1 CWH5850080
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
88
S-A75KE CU-A75KE / CS-A95KE CU-A95KE / CS-A125KE CU-A125KE
