18 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-A75KE / CU-A95KE>
NO. DESCRIPTION & NAME Q’TY CU-A75KE CU-A95KE REMARKS
1 CHASSY ASS’Y 1 CWD50K2037A CWD50K2038A
2 FAN MOTOR BRACKET 1 CWD54113
←
3 SCREW - FAN MOTOR BRACKET 4 CWH4580399
←
4 FAN MOTOR 1 CWA95245
←
0
5 SCREW - FAN MOTOR MOUNT 3 CWH55027
←
6 PROPELLER FAN 1 CWH00K052
←
7 NUT - PROPELLER FAN 1 CWH56032
←
8 COMPRESSOR 1 2RS127D3CA04 2PS174D3AA02 0
9 ANTI - VIBRATION BUSHING 3 CWH50077
←
10 NUT - COMPRESSOR MOUNT 3 CWH56000
←
11 CONDENSER 1 CWB32C043
←
12 TUBE ASS’Y (CHECK VALVE / CAPILLARY) 1 CWT01C638 CWT01C639
13 HOLDER COUPLING ASS’Y 1 CWH351011
←
14 4-WAY VALVE 1 CWB00002
←
0
15 3-WAY VALVE 1 CWB01479
←
0
16 2-WAY VALVE 1 CWB02307
←
0
17 STRAINER 1 CWB11025
←
18 V - COIL COMPLETE 1 CWA43C2002
←
0
19 SOUND PROOF BOARD 1 CWH15C081
←
20 SOUND PROOF MATERIAL
(FOR COMPRESSOR)
1 CWG302070 CWG302073
21 SOUND PROOF MATERIAL 1 - CWG302074
22 L - SHAPED PLATE 1 CWD60247
←
23 OVERLOAD PROTECTOR 1 CWA12345 CWA12346 0
24 HOLDER - O.L.P. 1 CWH7041200
←
25 TERMINAL COVER 1 CWH171011
←
26 NUT - TERMINAL COVER 1 CWH7080300
←
27 CONTROL BOARD 1 CWH10881
←
28 TERMINAL BOARD ASS’Y 1 CWA28K216
←
29 ELECTROLYTIC CAPACITOR 1 CWA32C045
←
0
30 ELECTROLYTIC CAPACITOR 1 CWA32C067
←
0
31 CAPACITOR - COMPRESSOR 1 CWA31653
(15µF, 440V)
CWA31646
(25µF , 370V)
0
32 HOLDER CAPACITOR 1 CWH30057
←
33 CAPACITOR - FAN MOTOR 1 CWA31602
(1.2µF, 400V)
←
0
34 ELECTROMAGNETIC SWITCH 1 CWA00111
←
0
35 ELECTROMAGNETIC SWITCH 1 CWA00059
←
0
36 TERMINAL BOARD ASS’Y 1 CWA4711012
←
37 TEMPERATURE RELAY 1 CWA14C1001
←
0
38 CABINET ASS’Y 1 CWE00K1019A
←
39 CABINET FRONT PLATE 1 CWE06C117A
←
40 CONTROL BOARD COVER 1 CWH131062
←
41 PLATE FOR CONTROL BOARD COVER 1 CWD911083
←
42 HANDLE 1 CWE16037C
←
43 L - TUBE 1 CWH5850080
←
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
