Dimensions Height inch (mm) 10 - 31/32 (279) 18 - 29/32 (480)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 7 - 27/32 (199) 9 - 21/32 (245)
Net Weight lb (kg) 20 (9.0) 71 (32.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 800
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 30% AES + Glass Fiber 12%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 32.2 - 34.5 65.8 - 57.5
Rate Output W 14 20
Fan Speed Low rpm Cooling; 875 - 800 —
Heating; 875 - 800
Medium rpm Cooling; 1,025 - 965 —
Heating; 1,025 - 965
High rpm Cooling; 1,250 - 1,210 —
Heating; 1,330 - 1,310
SuperHigh rpm Cooling; 1,330 - 1,310 —
Heating; 1,330 - 1,310
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 14 1 × 18
FPI 18 19
Size (W × H × L) mm 614 × 294 × 25.4 856 × 457.2 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(350)
Refrigerant (R-22) g (oz) — 935 (33.0)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 1,075, Heating; 325
Flow Rate l/min — Cooling; 5.2, Heating; 13.4
Inner Diameter mm — Cooling; 1.2, Heating; 1.4
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 25 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.0 µF, 400VAC 1.2 µF, 400VAC
•
Specifications are subject to change without notice for further improvement.
9
CS-A75KE CU-A75KE / CS-A95KE CU-A95KE / CS-A125KE CU-A125KE
