Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 14 1 × 20
FPI 21 18
Size (W × H × L) mm 614 × 294 × 25.4 782.9 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(410)
Refrigerant (R-22) g (oz) — 815 (28.8)
Thermostat Electronic Control —
Protection Device — 2 Stage Overload Protector
Capillary Tube Length mm — 535
Flow Rate l/min — 17.0
Inner Diameter mm — 1.7
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 1.5 µF, 400VAC
•
Specifications are subject to change without notice for further improvement.
11
CS-C75KE CU-C75KE / CS-C95KE CU-C95KE / CS-C125KE CU-C125KE
