Panasonic CS-C75KE User Manual

(Note)
•
“O” marked parts are recommended to be kept in stock.
16 Replacement Parts List
<Model: CS-C75KE / CS-C95KE / CS-C125KE>
NO. DESCRIPTION & NAME Q’TY CS-C75KE CS-C95KE CS-C125KE REMARKS
1 CHASSY COMPLETE 1 CWD50C338
← ←
2 PARTICULAR PIECE 1 CWD931019
← ←
3 FAN MOTOR 1 CWA921033 CWA921034 CWA921031 0
4 LEAD WIRE - FAN MOTOR 1 CWA67C2097
← ←
5 CROSS FLOW FAN 1 CWH02C060
← ←
6 BEARING 1 CWH64K007
← ←
7 SCREW - CROSS FLOW FAN 1 CWH4580304
← ←
8 EVAPORATOR & TUBE ASS’Y COMPLETE 1 CWB30C1058 CWB30C1061 CWB30C1060
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
← ←
10 ANTI VIBRATION BUSHING 1 — CWH50211
←
11 FLARE NUT (1/4”) 1 CWH6002140(1/4”)
← ←
12 FLARE NUT (3/8”) 1 CWT25005 (3/8”)
←
CWT25007 (1/2”)
13 DISCHARGE GRILLE COMPLETE 1 CWE20C2062
←
CWE20C2085
14 VERTICAL VANE WITH TAB 2 CWE24458
← ←
15 VERTICAL VANE 10 CWE24457
← ←
16 CONNECTING BAR 2 CWE26194
← ←
17 AIR SWING MOTOR 1 CWA98260
←
CWA98C033 0
18 LEAD WIRE - AIR SWING MOTOR 1 CWA67C2106
← ←
19 CAP FOR DRAIN TRAY 1 CWH52C003
← ←
20 HORIZONTAL VANE 1 CWE241027
← ←
21 CONTROL BOARD 1 CWH10965
← ←
22 POWER SUPPLY CORD 1 CWA20C2102
← ←
23 ELECTRONIC CONTROLLER 1 CWA742323
← ←
0
24 RECEIVER 1 CWA74919
← ←
0
25 INDICATOR COMPLETE 1 CWE39C1024
← ←
26 LEAD WIRE - INDICATOR 1 CWA67C2105
← ←
0
27 TERMINAL BOARD 1 CWA28C2028
←
CWA28C2027 0
28 INDICATOR HOLDER 1 CWD931018
← ←
29 TEMPERATURE SENSOR 1 CWA50C608
← ←
0
30 CONTROL BOARD FRONT COVER 1 CWH13456
← ←
31 CONTROL BOARD TOP COVER 1 CWH13457
← ←
32 REMOTE CONTROL COMPLETE 1 CWA75C2079
← ←
0
33 FRONT GRILLE COMPLETE 1 CWE11C2106
← ←
34 INTAKE GRILLE COMPLETE 1 CWE22C1006
← ←
35 DECORATION BASE COMPLETE 1 CWE35C1007
← ←
36 TAB 2 CWD931020
← ←
37 AIR FILTER 2 CWD00240
← ←
38 GRILLE DOOR 1 CWE141013
← ←
39 SCREW FOR FRONT GRILLE 2 XTN4+16C
← ←
40 CAP FOR FRONT GRILLE 2 CWH52267
← ←
41 DRAIN HOSE 1 CWH5880580
← ←
42 OPERATING INSTRUCTIONS 1 CWF563175
← ←
43 INSTALLATION INSTRUCTIONS 1 CWF612098
←
CWF612097
44 INSTALLATION PLATE 1 CWH36157
← ←
45 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1054
← ←
46 AIR PURIFYING FILTER COMPLETE 1 CWD00C1028
← ←
47 AIR PURIFYING FILTER (CATECHIN) 2 CWD001014
← ←
0
48 AIR PURIFYING FILTER (DEODORIZING) 2 CWD001033
← ←
0
49 REMOTE CONTROL HOLDER 1 CWH36161
← ←
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
75
CS-C75KE CU-C75KE / CS-C95KE CU-C95KE / CS-C125KE CU-C125KE
