21 Electronic Parts List
Note
<Electronic Controller Part No.: CWA742323>
SYMBOL DESCRIPTION & NAME PART NO.
BZ1 SOUND GENERATOR A48040
D1, D4 DIODE A541SR154-4
DB1 DIODE A54CS1VB20E
FUSE FUSE XBA2C20TR0
IC1 INTEGRATED CIRCUIT A52D0022GB14
IC2 INTEGRATED CIRCUIT A52BR9020F
IC3 INTEGRATED CIRCUIT A52A2003GR2
IC4 INTEGRATED CIRCUIT A52C040
IC5 INTEGRATED CIRCUIT A52C114
Q1 TRANSISTOR A55DC114EKTX
Q2, Q3 TRANSISTOR A55C2412KTX
Q4 TRANSISTOR A55D1484K
Q5 - Q8 TRANSISTOR A55DC143XKTX
RY-PWR ELECTRO MAGNETIC RELAY A001001
RY-SHi, RY-Hi, RY-M ELECTRO MAGNETIC RELAY A00160
SSR1, SSR2 TYRISTOR A56G3MC202PL
SW3 PUSH SWITCH A01059
T1 TRANSFORMER A401022
X1 RESONATOR A45CST4.09MG
ZD1 DIODE A54D7.5MT1B
ZNR1, ZNR2, ZNR3 DIODE ERZVEAV511
C-FM SH CAPACITOR A31698
CR1, CR2, CR3, CR4, CR5 SURGE ABSORBER A59014
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
