AIR SWING
TIMER
CLOCK
1
2
3
CO
O
L
MODE
ECONOMY
FAN SPEED
AUTO
MANUAL
ON OFF
CANCEL
SLEEP
SET
POWERFUL
OFF/ON
COOL
TEMP
HOW TO OPERATE
● Automatic, Cooling, Soft Dry, Fan
Display
Close the Cover
a
FAN
DRY
COOL
HI
AUTO
AUTO
LO
AUTO
a – Automatic Operation
• Once the Automatic Operation is selected, the indoor
temperature sensor operates automatically to select
the desired operation mode with Cooling or Soft Dry.
• After the operation mode have been selected, the
mode does not change.
• Temperature is not displayed on remote control during
Auto mode operation
■ Operation details
COOLING
SOFT DRY
25°C
22°C
Operation
Standard temperature
TEMPERATURE
23°C
Cooling Operation
• To set room temperature to your preference of cooling
comfort.
Setting
temperature
Soft Dry operation airflow with
10 mins. ON and 6 mins. OFF
alternately.
Switch to Soft Dry when setting temperature is
reached.
Cooling
Operation
DRYCOOL
COOL
– Soft Dry Operation
• A very gentle Cooling Operation. Consisting primarily of
dehumidifying. It does not lower the room temperature.
• During Soft Dry operation, the indoor fan operates at Low fan
speed.
DRY
1 Press to select the desired operation mode
When pressed, the display changes in this order.
2 Press to start the operation
POWER indicator LED (Green) on indoor unit will light up.
Press once more to stop operation.
3 Press to select room temperature
• a Automatic Operation
Display
- Operation with 2°C higher than standard temperature.
- Operation with standard temperature.
- Operation with 2°C lower than standard temperature.
• Cooling, Soft Dry operation
Press to increase temperature by 1°C.
Press to decrease temperature by 1°C.
– The temperature can be set between 16°C and 30°C.
– Recommended temperature
For Cooling: 26°C - 28°C.
For Soft Dry: 1°C - 2°C lower than room temperature.
34
S-C75KE CU-C75KE / CS-C95KE CU-C95KE / CS-C125KE CU-C125KE
