3 Product Specifications
Unit CS-C75KE CU-C75KE
Cooling Capacity kW
kcal/h
2.05 - 2.00
1,760 - 1,810
Moisture Removal l/h
Pint/h
1.3
2.7
Power Source Phase
V
Cycle
Single
230 - 220
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) 5.5 (200) - 5.3 (190) —
Indoor Air (Me) m
3
/min (cfm) 5.8 (210) - 5.5 (200) —
Indoor Air (Hi) m
3
/min (cfm) 7.0 (250) - 6.8 (240) —
Indoor Air (SHi) m
3
/min (cfm) 7.8 (280) - 7.7 (270) —
Noise Level dB (A) High 33 - 32, Low 26 - 26 High 46 - 45
Power level dB High 46 - 45 High 61 - 60
Electrical Data Input W 600 - 550
Running Current A 2.8 - 2.7
EER W/W (kcal/hw) 3.42 - 3.64 (2.93 - 3.13)
Starting Current A 12
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.7 —
Power Cord Length
Number of core-wire
m 2.0
3 (1.0 mm
2
)
—
—
Dimensions Height inch (mm) 10 - 31/32 (279) 18 - 29/32 (480)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 7 - 27/32 (199) 9 - 21/32 (245)
Net Weight lb (kg) 20 (9.0) 57 (26)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 500
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 30% AES + Glass Fiber 16%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 26.6 48.9
Rate Output W 10 20
Fan Speed Low rpm 835 - 810 —
Medium rpm 875 - 840 —
High rpm 1,055 - 1,030 730 - 670
SuperHigh rpm 1,175 - 1,160 —
6
S-C75KE CU-C75KE / CS-C95KE CU-C95KE / CS-C125KE CU-C125KE
