20 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-C125KE>
NO. DESCRIPTION & NAME Q’TY CU-C125KE REMARKS
1 CHASSY ASS’Y 1 CWD50K658A
2 FAN MOTOR BRACKET 1 CWD54254
3 SCREW - FAN MOTOR BRACKET 2 CWH55189
4 FAN MOTOR 1 CWA951071 0
5 SCREW - FAN MOTOR MOUNT 4 CWH55406
6 COMPRESSOR 1 2KS224D5CA02 0
7 ANTI - VIBRATION BUSHING 3 CWH50055
8 NUT - COMPRESSOR MOUNT 3 CWH4582065
9 PACKING - COMPRESSOR MOUNT 1 CWB81047
10 CONDENSER 1 CWB32C334
11 TUBE ASS’Y (STRAINER CAPILLARY) 1 CWT01C647
12 HOLDER COUPLING ASS’Y 1 CWH35177
13 2-WAY VALVE 1 CWB02514 0
14 3-WAY VALVE 1 CWB01480 0
15 SOUND PROOF BOARD 1 CWH15288
16 SOUND PROOF MATERIAL 1 CWG302075
17 WIRE NET 1 CWD04197A
18 AIR GUIDER PROPELLER FAN 1 CWD31138
19 OVERLOAD PROTECTOR 1 CWA12352 0
20 HOLDER - O.L.P. 1 CWH7041200
21 TERMINAL COVER 1 CWH171011
22 NUT - TERMINAL COVER 1 CWH7080300
23 CONTROL BOARD 1 CWH10972
24 TERMINAL BOARD ASS’Y 1 CWA28K217
25 CAPACITOR - COMPRESSOR 1 CWA31647
(30µF , 370V)
0
26 HOLDER CAPACITOR 1 CWH30057
27 CAPACITOR - FAN MOTOR 1 CWA31604
(1.5µF , 400V)
0
28 PROPELLER FAN ASS’Y 1 CWH00K087
29 NUT - PROPELLER FAN 1 CWH56053
30 CABINET SIDE PLATE (RIGHT) 1 CWE04217A
31 CABINET SIDE PLATE (LEFT) 1 CWE04220A
32 CABINET FRONT PLATE 1 CWE06K104A
33 HANDLE 1 CWE16037C
34 CONTROL BOARD COVER 1 CWH13461
35 PLATE FOR C. B. COVER 1 CWD91258
36 CABINET TOP PLATE 1 CWE03K035A
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
79
CS-C75KE CU-C75KE / CS-C95KE CU-C95KE / CS-C125KE CU-C125KE
