18 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-C75KE / CU-C95KE>
NO. DESCRIPTION & NAME Q’TY CU-C75KE CU-C95KE REMARKS
1 CHASSY ASS’Y 1 CWD50K2035A
←
2 FAN MOTOR BRACKET 1 CWD54113
←
3 SCREW - FAN MOTOR BRACKET 4 CWH4580399
←
4 FAN MOTOR 1 CWA951040
←
0
5 SCREW - FAN MOTOR MOUNT 3 CWH55027
←
6 PROPELLER FAN 1 CWH00K040
←
7 NUT - PROPELLER FAN 1 CWH56032
←
8 COMPRESSOR 1 2RS110D5CA04 2PS146D5BA04 0
9 ANTI - VIBRATION BUSHING 3 CWH50077
←
10 NUT - COMPRESSOR MOUNT 3 CWH56000
←
11 CONDENSER 1 CWB32C323 CWB32C119
12 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT01C589 CWT01C590
13 HOLDER COUPLING ASS’Y 1 CWH351011
←
14 3-WAY VALVE 1 CWB01438
←
0
15 2-WAY VALVE 1 CWB02277
←
0
16 SOUND PROOF MATERIAL 1 CWG302067 CWG302088
17 SOUND PROOF BOARD 1 CWH15266
←
18 L - SHAPED PLATE 1 CWD60247
←
19 OVERLOAD PROPECTOR 1 CWA12343 CWA12344 0
20 HOLDER - O.L.P. 1 CWH7041200
←
21 TERMINAL COVER 1 CWH171011
←
22 NUT - TERMINAL COVER 1 CWH7080300
←
23 CONTROL BOARD 1 CWH102081
←
24 TERMINAL BOARD ASS’Y 1 CWA28K217
←
25 CAPACITOR - COMPRESSOR 1 CWA31645
(20µF, 370V)
CWA31647
(30µF, 370V)
0
26 HOLDER CAPACITOR 1 CWH30057
←
0
27 CAPACITOR FAN MOTOR 1 CWA31602
(1.2µF, 400V)
←
28 CABINET ASS’Y 1 CWE00K1019A
←
29 CABINET FRONT PLATE 1 CWE06C117A
←
30 CONTROL BOARD COVER 1 CWH131062
←
31 PLATE FOR CONTROL BOARD COVER 1 CWD911083
←
32 HANDLE 1 CWE16037C
←
33 STRAINER 1 CWB11025
←
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
77
CS-C75KE CU-C75KE / CS-C95KE CU-C95KE / CS-C125KE CU-C125KE
