Panasonic CS-E10HB4EA - Sensible Capacity Chart

78
17.2. Sensible Capacity Chart
CS-E10HB4EA CU-E10HBEA
CS-E15HB4EA CU-E15HBEA
CS-E18HB4EA CU-E18HBEA
CS-E21HB4EAS CU-E21HBEA
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 2.48 1.88 0.57 2.32 1.80 0.61 2.16 1.73 0.65 1.96 1.65 0.70
19.0°C 2.50 0.62
19.5°C 2.72 1.97 0.58 2.55 1.89 0.62 2.37 1.82 0.67 2.15 1.73 0.72
22.0°C 2.97 2.04 0.59 2.77 1.96 0.63 2.58 1.89 0.68 2.35 1.81 0.73
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 4.07 3.08 1.19 3.80 2.96 1.28 3.53 2.84 1.37 3.21 2.70 1.48
19.0°C 4.10 1.30
19.5°C 4.46 3.23 1.21 4.17 3.10 1.31 3.88 2.99 1.40 3.53 2.84 1.51
22.0°C 4.87 3.35 1.24 4.55 3.22 1.33 4.23 3.11 1.42 3.85 2.96 1.53
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 4.76 3.61 1.40 4.45 3.46 1.51 4.14 3.33 1.61 3.76 3.16 1.74
19.0°C 4.80 1.53
19.5°C 5.23 3.78 1.43 4.89 3.63 1.54 4.55 3.50 1.64 4.13 3.33 1.77
22.0°C 5.70 3.92 1.45 5.32 3.77 1.56 4.95 3.64 1.67 4.50 3.47 1.80
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.85 4.44 1.88 5.47 4.26 2.02 5.09 4.09 2.16 4.63 3.89 2.33
19.0°C 5.90 2.05
19.5°C 6.43 4.65 1.91 6.01 4.46 2.06 5.59 4.30 2.20 5.08 4.09 2.37
22.0°C 7.00 4.82 1.95 6.54 4.63 2.10 6.09 4.47 2.24 5.53 4.26 2.42
TC - Total Cooling Capacity (kW) Indoor 27°C/19°C
SHC - Sensible Heat Capacity (kW) Outdoor 35°C/24°C
IP - Input Power (kW)
