2.2. CS-E15HB4EA CU-E15HBEA
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT / AS
C
O
O
L
I
N
G
Capacity
kW 4.10 (0.90 ~ 4.80)
BTU/h 14000 (3070 ~ 16400)
kCal/h 3530 (770 ~ 4130)
EER
W/W 3.15 (3.53 ~ 2.81)
Btu/hW 10.8 (12.00 ~ 9.60)
Noise Level
dB (A) Hi: 34, Lo: 26, Q-Lo: 23 Hi: 45
Power level dB Hi: 47 Hi: 58
H
E
A
T
I
N
G
Capacity
kW 5.10 (0.90 ~ 6.20)
BTU/h 17400 (3070 ~ 21100)
kCal/h 4390 (770 ~ 5330)
COP
W/W 2.88 (3.46 ~ 2.84)
Btu/hW 9.80 (11.8 ~ 9.7)
Noise Level
dB (A) Hi: 35, Lo: 28, Q-Lo: 25 Hi: 47
Power level dB Hi: 48 Hi: 60
Moisture Removal
l/h 2.3
pt/h 4.9
Air Volume
QLo
m
3
/min (ft
3
/min)
Cooling; 7.1 (250)
—
Heating; 8.5 (300)
Lo
m
3
/min (ft
3
/min)
Cooling; 7.9 (280)
—
Heating; 8.8 (310)
Me
m
3
/min (ft
3
/min)
Cooling; 9.2 (330)
—
Heating; 9.8 (350)
Hi
m
3
/min (ft
3
/min)
Cooling; 10.5 (370) Cooling; 46.8 (1650)
Heating; 10.8 (380) Heating; 48.5 (1710)
SHi
m
3
/min (ft
3
/min)
Cooling; 11.2 (400)
—
Heating; 11.6 (410)
Refrigeration Control Device — Expansion Valve
Refrigeration Oil
cm
3
— RB68A or Freol Alpha68M (400)
Refrigerant (R410A) g (oz) — 1.23k (43.4)
Dimension
Height mm (inch) 260 (10-1/4) 750 (29-17/32)
Width mm (inch) 575 (22-21/32) 875 (34-15/32)
Depth mm (inch) 575 (22-21/32) 345 (13-19/32)
Net Weight kg (lbs) 18 (40) 48 (106)
Pipe Diameter
Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 20 (65.6)
Height Difference m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 10 (32.8)
Drain Hose
Inner Diameter mm 30 —
Length mm 193 —
Compressor
Type — Hermetic Motor
Motor Type — Brushless (4-pole)
Rated Output W — 900
