15
Note: “ ” : Available
Remarks for CU-2E15GBE / CU-2E18CBPG
1. At least two indoor units must be connected.
2. The total nominal cooling capacity of indoor units that will be connected to outdoor unit must be within connectable
capacity range of indoor unit. (as shown in the table above)
Example: The indoor unit’s combination below is possible to connect to CU-2E15GBE. (Total nominal capacity of indoor
units is between 4.4kW to 5.6kW)
a. Two CS-E7HKEW only. (Total nominal cooling capacity is 4.4kW)
b. One CS-E7HKEW and one CS-E9HKEW. (Total nominal cooling capacity is 5.0kW)
Remarks for CU-3E18EBE / CU-3E23CBPG / CU-4E27CBPG
1. At least two indoor units must be connected.
2. The total nominal cooling capacity of indoor units that will be connected to outdoor unit must be within connectable
capacity range of indoor unit. (as shown in the table above)
Example: The indoor unit’s combination below is possible to connect to CU-3E23CBPG. (Total nominal capacity of indoor
units is between 5.0kW to 10.0kW)
a. Two CS-E9HKEW only. (Total nominal cooling capacity is 5.6kW)
b. Three CS-E12HKEW. (Total nominal cooling capacity is 9.6kW)
Capacity range of
connectable indoor
units
From 4.4kW to 5.6kW From 4.4kW to 6.4kW From 5.0kW to 9.0kW From 5.0kW to 10kW From 5.0kW to 13.6kW
P
I
P
I
N
G
L
E
N
G
T
H
1 room
maximum pipe
length (m)
20 20 25 25 25
Allowable
elevation (m)
10 10 15 15 15
Tota l
allowable pipe
length (m)
30 30
50 50 70
Total pipe
length for
maximum
chargeless
length (m)
20 20
30 30 40
Additional gas
amount over
chargeless
length (m)
20 20 20 20 20
