68
<Model: CS-E18HKEW>
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF NO. PART NAME & DESCRIPTION QTY. CS-E18HKEW REMARKS
1 CHASSY COMPLETE 1 CWD50C1520
2 FAN MOTOR 1 ARW61G8P30AC O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010
4 SCREW - CROSS FLOW FAN 1 CWH551146
5 BEARING ASS’Y 1 CWH64K007
6 EVAPORATOR 1 CWB30C1533
7 FLARE NUT (1/4”) 1 CWT251030
8 FLARE NU (1/2”) (5/8”) 1 CWT251032
9 HOLDER SENSOR 1 CWH32143
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2685
11 VERTICAL VANE 15 CWE241088
12 CONNECTING BAR 1 CWE261025
13 AIR SWING MOTOR 1 CWA98260+MJ O
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849
14 AIR SWING MOTOR 1 CWA98K1008 O
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C4445
16 HORIZONTAL VANE 1 CWE241228
17 HORIZONTAL VANE 1 CWE241229
18 CAP - DRAIN TRAY 1 CWH521096
19 BACK COVER CHASSIS 1 CWD932162B
20 CONTROL BOARD CASING 1 CWH102334
21 TERMINAL BOARD COMPLETE 1 CWA28C2305 O
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C3106 O
24 INDICATOR COMPLETE 1 CWE39C1174 O
25 INDICATOR HOLDER 1 CWD932817
26 INDICATOR HOLDER 1 CWD932818
27 SENSOR COMPLETE 1 CWA50C2122 O
28 CONTROL BOARD TOP COVER 1 CWH131209
29 CONTROL BOARD FRONT COVER 1 CWH131210
30 REMOTE CONTROL COMPLETE 1 CWA75C3175 O
31 FRONT GRILLE COMPLETE 1 CWE11C3898 O
32 INTAKE GRILLE COMPLETE 1 CWE22C1423 O
33 GRILLE DOOR 1 CWE141076
34 E-ION FILTER 2 CWD00K1005
36 SCREW - FRONT GRILLE 3 XTT4+16CFJ
37 CAP - FRONT GRILLE 3 CWH521062A
38 DRAIN HOSE 1 CWH851063
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
40 INSTALLATION PLATE 1 CWH36K1007
41 FULCRUM 2 CWH621073
42 E-ION AIR PURIFYING SYSTEM 1 CWH14C5600
43 ION-GENERATOR 1 CWH94C0014
51 ELECTRONIC CONTROLLER - POWER 1 CWA744758 O
52 OPERATING INSTRUCTION 1 CWF566009
53 OPERATING INSTRUCTION 1 CWF566016
54 INSTALLATION INSTRUCTION 1 CWF613370
55 INSTALLATION INSTRUCTION 1 CWF613371
