Unit CS-PV12CKE CU-PV12CKE
Cooling Capacity kW 3.52
Moisture Removal L/h 2.0
Power Source Phase
V
Cycle
Single
230
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Circulation Indoor Air (low) m
3
/min 7.3 —
Indoor Air (medium) m
3
/min 8.7 —
Indoor Air (high) m
3
/min 10.2 —
Outdoor Air m
3
/min — —
Noise Level dB(A) High40, Low31 High51
Electrical Data Input W 1170
Running Current A 5.3
EER W/W 3.01
Starting Current A 21.1
Piping Connection Port
(Flare piping)
Inch
Inch
G: half union 1/2"
L: half union 1/4"
G: 3-way valve 1/2"
L: 2-way valve 1/4"
Piping Size
(Flare piping)
Inch
Inch
G: gas side 1/2"
L: liquid side 1/4"
G: gas side 1/2"
L: liquid side 1/4"
Drain
Hose
Inner Diameter mm 12 —
Length m 0.6 —
Power Supply Cord Length
(Number of core-wire)
m 1.9
3 core-wire/1.5mm
2
—
—
Dimensions Height mm 275 540
Width mm 799 780
Depth mm 210 289
Net Weight kg 9.0 31
Compressor Type — Rotary(1 cylinder)
Rolling piston type
Motor Type — Induction(2 pole)
Rated Output W — 900
7
CS-PV9CKE CU-PV9CKE / CS-PV12CKE CU-PV12CKE
