6
Indoor CS-S10PKH (MALAYSIA) CS-S13PKH (MALAYSIA)
Model
Outdoor CU-S10PKH (MALAYSIA) CU-S13PKH (MALAYSIA)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
FV50S (250) FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 740 (26.1) R410A, 690 (24.4)
Height (I/D / O/D) mm (inch) 290 (11-7/16) 511 (20-1/8) 290 (11-7/16) 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) 650 (25-19/32) 870 (34-9/32) 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) 230 (9-1/16) 214 (8-7/16) 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) 20 (44) 9 (20) 30 (66)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 7.5 (24.6) 7.5 (24.6)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5 (16.4) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 15 (0.2) 15 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16.7 16.7
Drain Hose
Length mm 550 550
Fin Material Aluminium (Pre Coated) Aluminium (Pre Coated)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 17 2 × 15 × 17
Indoor Heat
Exchanger
Size (W × H × L) mm 610 × 315 × 25.4 610 × 315 × 25.4
Fin Material Aluminium (Blue Coated) Aluminium (Blue Coated)
Fin Type Slit Fin Louver Fin
Row × Stage × FPI 1.5 × 23 × 17 1 × 20 × 19
Outdoor Heat
Exchanger
Size (W × H × L) mm 25.4 × 483.0 × 553.4:573.4 22.0 × 508.0 × 708.4
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat – –
Protection Device – –
DRY BULB WET BULB DRY BULB WET BULB
Maximum °C 32 23 32 23
Indoor Operation Range
Minimum °C 16 11 16 11
Maximum °C 43 26 43 26
Outdoor Operation Range
Minimum °C 16 11 16 11
1. Cooling capacities are based on indoor temperature of 27°C DRY BULB (80.6°F DRY BULB), 19.0°C WET BULB (66°F WET BULB) and
outdoor air temperature of 35°C DRY BULB (95°F DRY BULB), 24°C WET BULB (75.2°F WET BULB)
