91
12.14.2.2 Judge Sunlight Intensity
• Based on sunlight sensor output voltage, the sunlight intensity value will be computed and logged to sunlight
intensity database.
• The sunlight sensor sensitivity could be adjusted:
SET
Press & release within 10s
Sensitivity Level 1: Less sensitive to sunlight intensity
Sensitivity Level 3: Default sensitive level
Sensitivity Level 5: More sensitive to sunlight intensity
Default: (Battery insert)
Set to Level. 3
Other than default
Display last set data
Transmit
solar radiation
level
&
after *2 secs
go back to
normal mode
Set to Level. 4
Press
Timer
1
Set to Level. 5
Set to Level. 1
Set to Level. 2
Remote control normal mode
SET
12.14.2.3 Judge Ambient Condition
• According to sunlight intensity over a period of time, the system will analyze the ambient condition is sunny,
cloudy or night.
12.14.2.4 Temperature Shift
• In a room without window or with thick curtain, the sunlight sensor will judge as cloudy/night.
