Panasonic CS-TZ25TKEW Service Manual

10
Model
Indoor CS-TZ20TKEW CS-TZ25TKEW
Outdoor CU-TZ20TKE CU-TZ25TKE
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Output Power W 500 500
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles)
Input Power W 47.3 47.3
Output Power W 30 30
Speed
QLo
Cool rpm 630 630
Heat rpm 730 730
Lo
Cool rpm 770 800
Heat rpm 820 850
Me
Cool rpm 940 1010
Heat rpm 1020 1070
Hi
Cool rpm 1120 1220
Heat rpm 1220 1290
SHi
Cool rpm 1170 1270
Heat rpm 1270 1340
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 840 830
Heat rpm 800 800
Moisture Removal L/h (Pt/h) 1.3 (2.7) 1.5 (3.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.27 (186) 5.27 (186)
Heat m
3
/min (ft
3
/min) 6.23 (220) 6.23 (220)
Lo
Cool m
3
/min (ft
3
/min) 6.62 (234) 6.90 (244)
Heat m
3
/min (ft
3
/min) 7.10 (251) 7.38 (261)
Me
Cool m
3
/min (ft
3
/min) 8.25 (291) 8.92 (315)
Heat m
3
/min (ft
3
/min) 9.02 (319) 9.50 (335)
Hi
Cool m
3
/min (ft
3
/min) 10.00 (350) 10.90 (385)
Heat m
3
/min (ft
3
/min) 10.90 (385) 11.60 (410)
SHi
Cool m
3
/min (ft
3
/min) 10.46 (369) 11.42 (403)
Heat m
3
/min (ft
3
/min) 11.42 (403) 12.09 (427)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 31.20 (1100) 30.00 (1060)
Heat m
3
/min (ft
3
/min) 29.70 (1050) 28.90 (1020)
Refrigeration
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm
3
FW50S (250) FW50S (250)
Refrigerant Type g (oz) R32, 580 (20.5) R32, 670 (23.7)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Charged Amount)
0.392 / 0.442 0.452 / 0.503
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 799 (31-15/32) / 780 (30-23/32) 799 (31-15/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 197 (7-25/32) / 289 (11-13/32) 197 (7-25/32) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 8 (18) / 26 (57) 8 (18) / 27 (60)
