Panasonic CS-TZ25TKEW Service Manual

134
20.2 Heat Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Heat mode at 30°C
Voltage: 230V
20.2.1 CS-TZ20TKEW/CU-TZ20TKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 1653 767 1948 865 2535 899 2521 671 2684 668
20 1656 726 2140 860 2610 920 2700 670 2792 668
16 1561 687 2207 823 2627 876 2883 669 2959 666
20.2.2 CS-TZ25TKEW/CU-TZ25TKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 2003 945 2458 1057 2885 977 3082 801 3281 797
20 2006 894 2700 1050 2970 1000 3300 800 3413 797
16 1890 846 2785 1005 2989 952 3523 799 3617 796
20.2.3 CS-TZ35TKEW/CU-TZ35TKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 2552 1271 3004 1359 3594 1231 3623 1052 3857 1046
20 2556 1203 3300 1350 3700 1260 4000 1050 4013 1046
16 2409 1139 3403 1292 3724 1199 4142 1049 4253 1044
20.2.4 CS-TZ42TKEW/CU-TZ42TKE
Indoor (°C) Outdoor WB (°C)
DB
-15 -7 2 7 12
TC IP TC IP TC IP TC IP TC IP
24 3184 1610 3550 1711 4549 1768 4669 1352 4971 1345
20 3189 1523 3900 1700 4930 1810 5000 1350 5171 1345
16 3005 1442 4022 1627 4714 1723 5338 1349 5480 1342
TC - Total Cooling Capacity (W)
SHC - Sensible Heat Capacity (W)
IP - Input Power (W)
