17.2.2 Operation mode during Heating Only Operation
 The table below shows the operation mode comparison when Heating Only Operation Mode Activated and
Deactivated.
Operation
Mode
Heating Only Operation Mode Activated Heating Only Operation Mode Deactivated
AUTO
After 30s sampling, regardless of the indoor intake or
outdoor intake temperature judgment, the unit will run
Heating operation.
After 30s sampling, the unit will judge the operation
mode base on remote controller temperature setting and
Indoor Intake Sensor (New Auto Mode) or Outdoor
Intake Sensor (Old Auto Mode).
HEAT The unit will run Heating operation. The unit will run Heating operation.
COOL The unit will stop and Power LED blinking. The unit will run Cooling operation.
DRY The unit will stop and Power LED blinking. The unit will run Cooling Dry operation.
NANOE-G
Stand-alone
The unit will stop and Power LED blinking. The unit will run Nanoe-G Stand-alone operation.
Force Cooling
The unit will run Force Cooling Operation for
X_CTRYTM [15] minutes
The unit will run Force Cooling operation.
Force Heating The unit will run Force Heating operation. The unit will run Force Heating operation.
AUTO
(with Timer)
The unit will turn ON by the timer and run Auto
Operation. After 30s sampling, regardless of the indoor
intake or outdoor intake temperature judgment, the unit
will run Heating operation.
The unit will turn ON by the timer and run Auto
Operation. After 30s sampling, the unit will judge the
operation mode base on remote controller temperature
setting and Indoor Intake Sensor (New Auto Mode) or
Outdoor Intake Sensor (Old Auto Mode).
HEAT
(with Timer)
The unit will turn ON by the timer and run Heating
Operation.
The unit will turn ON by the timer and run Heating
Operation.
COOL
(with Timer)
The unit will not turn ON by the timer. Power LED
blinking.
The unit will turn ON by the timer and run Cooling
Operation.
DRY
(with Timer)
The unit will not turn ON by the timer. Power LED
blinking.
The unit will turn ON by the timer and run Cooling Dry
Operation.
Cooling
Test Mode
The unit will stop and Power LED blinking.
The unit will operate according to specify Cooling test
mode operation parameter.
Heating
Test Mode
The unit will operate according to specify Heating test
mode operation parameter.
The unit will operate according to specify Heating test
mode operation parameter.
17.3 Remote Control Button
17.3.1 SET Button
 To check remote control transmission code and store the transmission code to EEPROM:
o Press “Set” button by using pointer.
o Press “Timer Set” button until a “beep” sound is heard as confirmation of transmission code changed.
 To limit set temperature range for COOL & DRY, HEAT mode.
o Press “Set” button by using pointer.
o Press TEMP increment or decrement button to choose No. 3.
o Press Timer increment or decrement button to select desired temperature low limit of set temperature for
COOL & DRY mode.
o Press Timer Set button to confirm low limit selection.
o Press TEMP increment or decrement button to choose No. 4.
o Press Timer decrement or increment button to select desired temperature high limit of set temperature for
COOL & DRY mode.
o Press Timer Set button to confirm high limit selection.
o Press TEMP increment or decrement button to choose No. 5.
o Press Timer increment or decrement button to select desired temperature low limit of set temperature for
HEAT mode.
o Press Timer Set button to confirm low limit selection.
o Press TEMP increment or decrement button to choose No. 6.
o Press Timer decrement or increment button to select desired temperature high limit of set temperature for
HEAT mode.
o Press Timer Set button to confirm high limit selection.
o LCD returns to original display if remote control does not operate for 30 seconds or press Timer Cancel
button.
