SAFETY
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-TZ20TKEW CS-TZ25TKEW CS-TZ35TKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C00440 ← ←
2 FAN MOTOR 1 L6CBYYYL0195 ← ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1159 ← ←
4 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ←
5 BEARING ASSY 1 CWH64K1010 ← ←
6 EVAPORATOR 1 ACXB30C02730 ← ←
7 FLARE NUT (LIQUID) 1 CWT251030 ← ←
8 FLARE NUT (GAS) 1 CWT251031 ← ←
10 BACK COVER CHASSIS 1 CWD933857A ← ←
11 CONTROL BOARD CASING 1 ACXH10-00870 ← ←
12 TERMINAL BOARD COMPLETE 1 ACXA28C00260 ← ← O
14 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C12070 ACXA73C12080 ACXA73C12090 O
15
ELECTRONIC CONTROLLER -
INDICATOR
1 ACXA73-06360 ← ← O
16 INDICATOR HOLDER 1 ACXD93-02460 ← ←
17 SENSOR COMPLETE 1 CWA50C2664 ← ← O
18 DISCHARGE GRILLE COMPLETE 1 ACXE20C00850 ← ←
19 VERTICAL VANE 8 ACXE24-00590 ← ←
20 CONNECTING BAR 2 ACXE26-00250 ← ←
21 FULCRUM 1 ACXH62-00120 ← ←
22 CAP - DRAIN TRAY 1 CWH521259 ← ←
23 AIR SWING MOTOR 1 CWA981264 ← ← O
23A AIR SWING MOTOR 1 CWA981299 ← ←
24 HORIZONTAL VANE COMPLETE 1 ACXE24C00940 ← ←
24A HORIZONTAL VANE COMPLETE 1 ACXE24C00950 ← ←
26
CONTROL BOARD COVER -
COMPLETE
1 ACXH13C00180 ← ←
27 REMOTE CONTROL COMPLETE 1 ACXA75C00450 ← ← O
28 FRONT GRILLE COMPLETE 1 ACXE10C02660 ← ← O
29 INTAKE GRILLE COMPLETE 1 ACXE22C00760 ← ←
30 GRILLE DOOR COMPLETE 1 CWE14C1112 ← ←
31 AIR FILTER 2 CWD001385 ← ← O
32 SCREW - FRONT GRILLE 3 XTT4+16CFJ ← ←
33 CAP - FRONT GRILLE 2 ACXH52-00140 ← ←
34 DRAIN HOSE 1 CWH851173 ← ←
35 INSTALLATION PLATE 1 CWH361147 ← ←
36
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ←
37 AIR PURIFYING FILTER 1 CWD00C1293 ← ←
38 OPERATING INSTRUCTION 1 ACXF55-04100 ← ←
39 OPERATING INSTRUCTION 1 ACXF55-04110 ← ←
40 INSTALLATION INSTRUCTION 1 ACXF60-05670 ← ←
41 INSTALLATION INSTRUCTION 1 ACXF60-05680 ← ←
42 INSTALLATION INSTRUCTION 1 ACXF60-05690 ← ←
43 INSTALLATION INSTRUCTION 1 ACXF60-05700 ← ←
44 INSTALLATION INSTRUCTION 1 ACXF60-05710 ← ←
45 INSTALLATION INSTRUCTION 1 ACXF60-05720 ← ←
46 INSTALLATION INSTRUCTION 1 ACXF60-05730 ← ←
47 INSTALLATION INSTRUCTION 1 ACXF60-05770 ← ←
