Panasonic CS-TZ25ZKEW Service Manual

38
6.2 Outdoor Unit
6.2.1 CU-TZ20ZKE CU-TZ25ZKE CU-RZ25ZKE
6.2.2 CU-TZ35ZKE CU-TZ42ZKE CU-RZ35ZKE
(18)
69.5 61.6
542
28939
570
22
(104.7)
67.6780
85.5
155.2 34.3
60.5104.9
Space necessary for
installation
Anchor Bolt Pitch
320 x 570
<Side View>
<Side View> <Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
1000 mm
100 mm
100 mm
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
Space necessary for
installation
Anchor Bolt Pitch
320 x 570
1000 mm
100 mm
100 mm
570.3
39
289
.4
104.9
60.5
34.3
155.2
541.7
61.6
69.5
(18)
85.5
(104.7)
779.6
67.6
22
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
