14.4 Airflow Direction
 There are two types of airflow, vertical airflow (directed by horizontal vane) and horizontal airflow (directed by
vertical vanes).
 Control of airflow direction can be automatic (angles of direction is determined by operation mode, heat
exchanger temperature and intake air temperature) and manual (angles of direction can be adjusted using
remote control).
14.4.1 Vertical Airflow
(TZ20/25/35/42/50ZK RZ25/35/50ZK)
Operation
Mode
Airflow Direction
Inner Vane Angle (°)
measured from reference point
Outer Vane Angle (°)
measured from reference point
1 2 3 4 5 1 2 3 4 5
Cooling
AUTO
Not yet achieve
set temp.
5 ~ 45 0 ~ 40
Achieve set temp. 5 0
SWING 5 ~ 45 0 ~ 40
MANUAL 5 21 30 38 45 0 17 25 33 40
Soft Dry
AUTO
Not yet achieve
set temp.
5 ~ 45 0 ~ 40
Achieve set temp. 5 0
SWING 5 ~ 45 0 ~ 40
MANUAL 5 21 30 38 45 0 17 25 33 40
Heating
AUTO
A 21 17
B 52 47
C 21 17
SWING
Discharge air temp.
is cold
21 17
Discharge air temp.
is warm
41 ~ 61 36 ~ 56
MANUAL 21 31 41 52 61 17 26 36 47 56
(TZ60/71ZK)
Operation
Mode
Airflow Direction
Inner Vane Angle (°) Outer Vane Angle (°)
1 2 3 4 5 1 2 3 4 5
Cooling/
Dry
Auto
Not yet achieve
set temperature
13 ~ 52 6 ~ 34
Achieve set
temperature
13 6
Auto Swing 13 ~ 52 6 ~ 34
Manual 13 20 31 42 52 6 17 23 28 34
Heating
Manual 20 27 35 53 65 17 25 34 39 49
Auto
A 20 17
B 35 34
C 20 17
Air Swing
Lower Evaporator
Temperature Zone
20 17
Higher Evaporator
Temperature Zone
35 ~ 65 34 ~ 49
