Panasonic CS-Z20VKEW

194
SAFETY
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-XZ20VKEW CS-XZ25VKEW CS-XZ35VKEW REMARK
1 CHASSIS COMPLETE 1 CWD50C1605 ← ←
2 FAN MOTOR 1 L6CBYYYL0175 ← ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ← ←
4 BEARING ASSY 1 CWH64K1010 ← ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ←
6 PARTICULAR PIECE 1 CWD933067A ← ←
7 EVAPORATOR 1 CWB30C4659 ACXB30C00920 ←
8 FLARE NUT (LIQUID) 1 CWT251030 ← ←
9 FLARE NUT (GAS) 1 CWT251031 ← ←
10 CONTROL BOARD CASING 1 ACXH10-00200 ← ←
11 PARTICULAR PIECE - COVER 1 CWD933138 ← ←
12 TERMINAL BOARD COMPLETE 1 ACXA28C05590 ← ← O
13 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C50760 ACXA73C50920 ACXA73C50930 O
14 ELECTRONIC CONTROLLER - SUB 1 ACXA73-28560 ← ← O
15
ELECTRONIC CONTROLLER -
INDICATOR
1 ACXA73-08140 ← ← O
16
ELECTRONIC CONTROLLER -
RECEIVER
1 ACXA73-07240 ← ← O
17 HOLDER - RECEIVER 1 ACXD93-00700 ← ←
18 INDICATOR HOLDER 1 ACXD93-00930 ← ←
20 SENSOR COMPLETE 1 CWA50C2664 ← ← O
21 GENERATOR COMPLETE 1 ACXH94C00960 ← ←
22 ELECTRONIC CONTROLLER - WIFI 1 ACXA73-28520 ← ←
23 CONTROL BOARD TOP COVER 1 ACXH13-00190 ← ←
24 DISCHARGE GRILLE COMPLETE 1 ACXE20C05030 ← ←
25 BACK COVER CHASSIS 1 CWD933233A ← ←
26 FULCRUM 1 ACXH62-00040 ← ←
27 VERTICAL VANE 8 CWE241457 ← ←
28 CONNECTING BAR 1 CWE261314 ← ←
30 AIR SWING MOTOR 1 ACXA98K00020 ← ← O
31 AIR SWING MOTOR 1 ACXA98-01990 ← ← O
32 AIR SWING MOTOR 1 ACXA98-01960 ← ← O
33 CAP - DRAIN TRAY 1 CWH521259 ← ←
34 HORIZONTAL VANE COMPLETE 1 ACXE24C00390 ← ←
35 HORIZONTAL VANE COMPLETE 1 ACXE24C03830 ← ←
36 DUCT - COMPLETE 1 ACXD22C00230 ← ←
37
CONTROL BOARD COVER -
COMPLETE
1 ACXH13C00150 ← ←
38 REMOTE CONTROL COMPLETE 1 ACXA75C16210 ← ← O
39 FRONT GRILLE COMPLETE 1 ACXE10C09130 ACXE10C09140 ← O
40 INTAKE GRILLE COMPLETE 1 ACXE22K00120 ← ←
41 GRILLE DOOR COMPLETE 1 CWE14C1091 ← ←
42 AIR FILTER 2 CWD001279 ← ← O
43 SCREW - FRONT GRILLE 3 XTT4+16CFJ ← ←
44 CAP - FRONT GRILLE 2 ACXH52-00020A ← ←
45 DRAIN HOSE 1 ACXH85-00210 ← ←
46 INSTALLATION PLATE 1 CWH361147 ← ←
47
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ←
49 OPERATING INSTRUCTION 1 ACXF55-22540 ← ←
50 OPERATING INSTRUCTION 1 ACXF55-22550 ← ←
51 OPERATING INSTRUCTION 1 ACXF55-22700 ← ←
