Panasonic CS-Z20VKEW

31
7. Refrigeration Cycle Diagram
7.1 CS-Z20VKEW CU-Z20VKE CS-Z25VKEW CU-Z25VKE
CS-Z35VKEW CU-Z35VKE CS-Z42VKEW CU-Z42VKE
CS-XZ20VKEW CU-Z20VKE CS-XZ25VKEW CU-Z25VKE
CS-XZ35VKEW CU-Z35VKE
INDOOR OUTDOOR
INTAKE
AIR
TEMP.
SENSOR
AIR
TEMP.
SENSOR
PIPE
TEMP.
SENSOR 1
PIPE
TEMP.
SENSOR 2
TANK
SENSOR
PIPE
TEMP.
SENSOR
LIQUID
SIDE
2-WAY
VALVE
3-WAY
VALVE
GAS
SIDE
COOLING
HEAT EXCHANGER
(EVAPORATOR)
HEATING
COMPRESSOR
4-WAYS VALVE
CONDENSER
MUFFLER
MUFFLER
STRAINER
EXPANSION
VALVE
