Panasonic CS-Z20VKEW

197
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-Z50VKEW CS-Z71VKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C01590 ←
2 FAN MOTOR 1 L6CBYYYL0193 L6CBYYYL0194 O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1136 ←
4 BEARING ASSY 1 CWH64K1010 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 PARTICULAR PIECE 1 CWD933067B ←
7 EVAPORATOR 1 ACXB30C02760 ACXB30C01700
8 FLARE NUT (LIQUID) 1 CWT251030 ←
9 FLARE NUT (GAS) 1 CWT251032 CWT251033
10 CONTROL BOARD CASING 1 ACXH10-00720 ←
11 PARTICULAR PIECE - COVER 1 CWD933138 ←
12 TERMINAL BOARD COMPLETE 1 ACXA28C05590 ← O
13 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C50950 ACXA73C50960 O
14 ELECTRONIC CONTROLLER - SUB 1 ACXA73-28560 ← O
15 ELECTRONIC CONTROLLER - INDICATOR 1 ACXA73-29790 ← O
18 INDICATOR HOLDER 1 ACXD93-01960 ←
19 INDICATOR HOLDER 1 ACXD93-01970 ←
20 SENSOR COMPLETE 1 CWA50C3226 CWA50C2664 O
21 GENERATOR COMPLETE 1 ACXH94C00970 ←
22 ELECTRONIC CONTROLLER - WIFI 1 ACXA73-28520 ←
23 CONTROL BOARD TOP COVER 1 ACXH13-00430 ←
24 DISCHARGE GRILLE COMPLETE 1 ACXE20C00490 ←
25 BACK COVER CHASSIS 1 ACXD93-10180 ←
26 FULCRUM 2 ACXH62-00080 ←
27 VERTICAL VANE 11 ACXE24-00400 ←
28 CONNECTING BAR 1 ACXE26-00190 ←
29 CONNECTING BAR 1 ACXE26-00200 ←
30 AIR SWING MOTOR 1 ACXA98K00030 ← O
31 AIR SWING MOTOR 1 ACXA98-01990 ← O
32 AIR SWING MOTOR 1 ACXA98-02000 ← O
33 CAP - DRAIN TRAY 1 CWH521259 ←
34 HORIZONTAL VANE COMPLETE 1 ACXE24C00550 ←
35 HORIZONTAL VANE COMPLETE 1 ACXE24C00540 ←
36 DUCT - COMPLETE 1 ACXD22C00240 ←
37 CONTROL BOARD COVER - COMPLETE 1 ACXH13C00150 ←
38 REMOTE CONTROL COMPLETE 1 ACXA75C16210 ← O
39 FRONT GRILLE COMPLETE 1 ACXE10C09090 ACXE10C09100 O
40 INTAKE GRILLE COMPLETE 1 ACXE22K00160 ←
41 GRILLE DOOR COMPLETE 1 ACXE14C00050 ←
42 AIR FILTER 2 ACXD00-00250 ← O
43 SCREW - FRONT GRILLE 4 XTT4+16CFJ ←
44 CAP - FRONT GRILLE 3 ACXH52-00100 ←
45 DRAIN HOSE 1 ACXH85-00210 ←
46 INSTALLATION PLATE 1 CWH361098 ←
47 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
49 OPERATING INSTRUCTION 1 ACXF55-22540 ←
50 OPERATING INSTRUCTION 1 ACXF55-22550 ←
51 OPERATING INSTRUCTION 1 ACXF55-22700 ←
