Panasonic CS-Z20VKEW

202
SAFETY
REF.
NO.
PART NAME & DESCRIPTION QTY. CU-Z20VKE CU-Z25VKE CU-Z35VKE REMARK
1 CHASSIS COMPLETE 1 CWD52K1399 ← ←
2 FAN MOTOR BRACKET 1 CWD541157 ← ←
3 SCREW - FAN MOTOR BRACKET 2 CWH551217 ← ←
4 FAN MOTOR 1 L6CAYYYL0064 ← ← O
5 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ←
6 PROPELLER FAN ASSY 1 CWH03K1100 ← ←
7 NUT - PROPELLER FAN 1 CWH56053J ← ←
8 COMPRESSOR 1 KSK75D43UEE 9RS102XMA21 ← O
10 ANTI - VIBRATION BUSHING 3 ACXH50-00970 CWH50077 ←
11 NUT - COMPRESSOR MOUNT 3 CWH561096 ← ←
12 CONDENSER 1 ACXB32C15080 ACXB32C00760 ←
14 DISCHARGE MUFFLER 1 CWB121021 ← ←
15 HOLDER COUPLING 1 CWH351233 ← ←
16 4-WAYS VALVE 1 ACXB00-00130 ← ← O
17 DISCHARGE MUFFLER (4 W. VALVE) 1 CWB121010 ← ←
19 2-WAYS VALVE (LIQUID) 1 CWB021180J CWB021654 ← O
20 3-WAY VALVE (GAS) 1 CWB011374 ← ← O
21 TERMINAL COVER 1 ACXH17-01460 CWH171039A ←
22 NUT - TERMINAL COVER 1 ACXH56-00460 CWH7080300J ←
24 V-COIL COMPLETE 1 ACXA43C00250 ← ← O
25 O-RING 1 ACXB81-06510 ← ←
26 V-COIL COMPLETE 1 ACXA43C06110 ← ← O
27 SOUND PROOF BOARD 1 CWH151427 CWH151428 ←
28 REACTOR 1 G0C752J00004 G0C392J00037 ← O
29 SOUND PROOF MATERIAL - TOP 1 ACXG30-09030 CWG302314 ←
30 SOUND PROOF MATERIAL - BODY 1 ACXG30-09020 CWG302948 ←
31 SOUND PROOF MATERIAL 1 ACXG30-08500 CWG302316 ←
33 SENSOR CO - COMP TEMP 1 CWA50C2830 CWA50C2205 ← O
34 CONTROL BOARD COVER - TOP 1 ACXH13-00450 ← ←
35 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C52130R ACXA73C50160R ACXA73C50170R O
36 TERMINAL BOARD ASSY 1 CWA28K1298 ← ← O
37 CABINET SIDE PLATE CO. 1 ACXE04C00200 ACXE04C00460 ←
38
SENSOR CO - AIR TEMP AND PIPE
TEMP
1 CWA50C3079 ← ← O
39 CABINET SIDE PLATE 1 CWE041858A ← ←
40 CABINET FRONT PLATE CO. 1 CWE06C1566 ← ←
41 CABINET TOP PLATE 1 CWE031230A ← ←
42 PLATE - C. B. COVER TERMINAL 1 CWH131301 ← ←
43 CONTROL BOARD COVER CO. 1 CWH13C1359 ← ←
45 STRAINER 1 CWB11094 ← ←
47 EXPANSION VALVE 1 CWB051078 ← ←
50 WIRE NET 1 ACXD04-00040A ← ←
52 BAG - COMPLETE 1 CWG87C900 ← ←
53 PANASONIC BADGE 1 CWE373439 ← ←
56 INSTALLATION INSTRUCTION 1 ACXF60-33670 ← ←
57 INSTALLATION INSTRUCTION 1 ACXF60-33680 ← ←
58 INSTALLATION INSTRUCTION 1 ACXF60-33690 ← ←
