3. Specifications
Model
Indoor CS-Z25UD3EAW CS-Z35UD3EAW
Outdoor CU-Z25UBEA CU-Z35UBEA
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 2.50 3.20 0.85 3.50 4.00
BTU/h 2900 8530 10900 2900 11900 13600
Kcal/h 730 2150 2750 730 3010 3440
Running Current A – 2.70 – – 4.10 –
Input Power W 240 580 850 240 910 1.19k
Annual Consumption kWh – 290 – – 455 –
EER
W/W 3.54 4.31 3.76 3.54 3.85 3.36
BTU/hW 12.08 14.71 12.82 12.08 13.08 11.43
Kcal/hW 3.04 3.71 3.24 3.04 3.31 2.89
ErP
Pdesign kW 2.5 3.5
SEER (W/W) 5.9 5.8
Annual
Consumption
kWh 148 211
Class A+ A+
Power Factor % – 93 – – 97 –
Indoor Noise (H / L / QLo)
dB-A 33 / 27 / 24 33 / 27 / 24
Power Level dB 49 / – 49 / –
Outdoor Noise (H / L)
dB-A 46 / – 48 / –
Power Level dB 61 / – 63 / –
Heating
Capacity
kW 0.85 3.20 4.60 0.85 4.20 5.10
BTU/h 2900 10900 15700 2900 14300 17400
Kcal/h 730 2750 3960 730 3610 4390
Running Current A – 3.60 – – 4.90 –
Input Power W 230 800 1.25k 230 1.10k 1.42k
COP
W/W 3.70 4.00 3.68 3.70 3.82 3.59
BTU/hW 12.61 13.63 12.56 12.61 13.00 12.25
Kcal/hW 3.17 3.44 3.17 3.17 3.28 3.09
ErP
Pdesign kW 2.6 2.8
Tbivalent °C -10 -10
SCOP (W/W) 4.2 4.1
Annual
Consumption
kWh 867 956
Class A+ A+
Power Factor % – 97 – – 98 –
Indoor Noise (H / L / QLo)
dB-A 35 / 27 / 24 35 / 27 / 24
Power Level dB 51 / – 51 / –
Outdoor Noise (H / L)
dB-A 47 / – 48 / –
Power Level dB 62 / – 63 / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.33 / 1.11k / 3.00 3.70 / 1.26k / 2.94
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 2.60 / 1.20k / 2.17 3.00 / 1.25k / 2.40
Max Current (A) / Max Input Power (W) 5.6 / 1.25k 6.6 / 1.42k
Starting Current (A) 3.60 4.90
