36
11.2 Outdoor Unit
11.2.1 Main Printed Circuit Board
11.2.1.1 CU-Z25UBEA CU-Z35UBEA
POWER
TRANSISTOR
(IPM)
CURRENT
TRANSFORMER
(CT)
CN-DEMAND
CN-TH1
CN-MTR1
CN-TANK
CN-HOT
CN-MTR2
CN-V1
CN-STM
AC-BLK
DATA
AC-WHT
FG1
FG2
