Panasonic CS-Z25UFEAW Service Manual

131
20.2 Heat Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Heat mode at 30°C Voltage: 230V
20.2.1
CS-Z25UD3EAW CU-Z25UBEA
Indoor (°C) Outdoor WB (°C)
DB
-15
-7
2 7 12
TC IP TC IP TC IP TC IP TC IP
24 2379 1181 2155 1138 2846 1048 3028 801 3714 697
20 2380 1040 2600 1200 3330 1110 3200 800 4151 746
16 2246 1019 2412 972 3391 995 3477 802 4417 744
20.2.2
CS-Z35UD3EAW CU-Z35UBEA
Indoor (°C) Outdoor WB (°C)
DB
-15
-7
2 7 12
TC IP TC IP TC IP TC IP TC IP
24 2464 1317 2486 1185 3150 1190 3969 1102 4868 1103
20 2465 1160 3000 1250 3700 1260 4200 1100 5442 1181
16 2326 1136 2783 1012 3754 1129 4558 1103 5789 1178
20.2.3
CS-Z50UD3EAW CU-Z50UBEA
Indoor (°C) Outdoor WB (°C)
DB
-15
-7
2 7 12
TC IP TC IP TC IP TC IP TC IP
24 3471 1706 4450 1971 4995 1980 5805 1814 6285 1812
20 3699 1695 4500 1950 5220 1950 6222 1820 6849 1823
16 3946 1678 4049 1724 5249 1907 6695 1824 7314 1819
20.2.4
CS-Z60UD3EAW CU-Z60UBEA
Indoor (°C) Outdoor WB (°C)
DB
-15
-7
2 7 12
TC IP TC IP TC IP TC IP TC IP
24 4021 2042 5043 2345 5550 2335 6531 2153 7071 2151
20 4285 2028 5100 2320 5800 2300 7000 2160 7705 2163
16 4571 2008 4589 2051 5832 2250 7532 2164 8228 2159
TC - Total
Heating Capacity (W)
IP - Input Power (W)
