Panasonic CS-Z25UFEAW Service Manual

150
SAFETY REF NO. PART NAME & DESCRIPTION QTY. CS-Z50UD3EAW CS-Z60UD3EAW REMARK
1 CABINET TOP PLATE - COMPLETE 1 CWE03C1169 ←
2 FOAMED STYRENE COMPLETE 1 CWG07C1094 ←
3 FOAMED STYRENE COMPLETE 1 CWG07C1089 ←
4 FOAMED STYRENE COMPLETE 1 CWG07C1090 ←
5 BULKHEAD 1 CWD531059 ←
6 CABINET SIDE PLATE - COMPLETE 1 CWE04C1565 ←
7 CABINET SIDE PLATE - COMPLETE 1 CWE04C1566 ←
8 PARTICULAR PLATE 4 CWD912571 ←
9 FAN MOTOR BRACKET 1 CWD541246 ←
10 SCREW - FAN MOTOR BRACKET 6 CWH55406J ←
11 PUMP - COMPLETE 1 CWB53C1056 ← O
12 ANTI - VIBRATION BUSHING 3 CWH501131 ←
13 FLOAT SWITCH COMPLETE 1 CWA12C1034 ← O
14 DRAIN NOZZLE 1 CWH411027 ←
15 FLEXIBLE PIPE - COMPLETE 1 CWH85C1120 ←
16 PLATE SPRING 1 CWH711022 ←
17 WIRE SPRING 1 CWH722018 ←
18 PARTICULAR PIECE - COMPLETE 1 CWD93C1191 ←
19 FIN & TUBE EVAPORATER - COMPLETE 1 ACXB30C10370 ← O
20 FLARE NUT (1/4") 1 CWT251030 ←
21 FLARE NUT (1/2") 1 CWT251032 ←
22 HOLDER - SENSOR 2 CWH32143 ←
23 SENSOR COMPLETE 1 ACXA50C00030 ← O
24 BLOWER WHEEL ASS'Y 2 CWH01K1041 ←
25 FAN MOTOR 1 L6CBYYYL0179 ← O
26 FAN MOTOR BRACKET 2 CWD541265 ←
27 SCREW - FAN MOTOR BRACKET 2 CWH551049J ←
28 AIR GUIDER B.W. 2 CWD321112 ←
29 AIR GUIDER B.W. 2 CWD321113 ←
30 DRAIN PAN - COMPLETE 1 CWH40C1134 ←
31 CONTROL BOARD A'SSY 1 CWH10K1262 ←
32 ELECTRONIC CONTROLLER - (MAIN) 1
ACXA73C40620 ACXA73C40630 O
33 TERMINAL BOARD ASS'Y 1
CWA28K1161 ←
35 TRANSFORMER - COMPLETE 1
CWA40C1106 ← O
36 CONTROL BOARD COVER 1 ACXH13C04450 ←
37 CABINET BOTTOM PLATE - COMPLETE 1 CWE05C1014 ←
38 CABINET TOP PLATE 1 CWE031215 ←
39 AIR FILTER 1 CWD001390 ←
40 ACCESSORY - COMPLETE 1 CWH82C2111 ←
41 WIRED REMOTE CONTROL COMPLETE 1 CWA75C4264 ← O
42 REMOTE CONTROL CABLE 1 CWA221081 ←
43 OPERATING INSTRUCTION 1 ACXF55-17690 ←
44 OPERATING INSTRUCTION 1 ACXF55-17700 ←
45 OPERATING INSTRUCTION 1 ACXF55-17960 ←
46 INSTALLATION INSTRUCTION 1 ACXF60-26230 ←
47 INSTALLATION INSTRUCTION 1 ACXF60-26240 ←
48 INSTALLATION INSTRUCTION 1 ACXF60-26250 ←
49 INSTALLATION INSTRUCTION 1 ACXF60-26260 ←
50 INSTALLATION INSTRUCTION 1 ACXF60-26270 ←
51 INSTALLATION INSTRUCTION 1 ACXF60-26280 ←
