153
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-Z25UBEA REMARK
1 CHASSIS COMPLETE 1 CWD52K1399
2 SOUND PROOF MATERIAL (TOP) 1 CWG302314
3 FAN MOTOR BRACKET 1 CWD541157
4 SCREW - FAN MOTOR BRACKET 2 CWH551217
5 FAN MOTOR 1 L6CAYYYL0064 O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J
7 PROPELLER FAN ASSY 1 CWH03K1100
8 NUT - PROPELLER FAN 1 CWH56053J
9 COMPRESSOR 1 9RS102XFA21 O
10 ANTI - VIBRATION BUSHING 3 CWH50077
11 NUT - COMPRESSOR MOUNT 3 CWH561096
12 CONDENSER 1 ACXB32C00760
13 EXPANSION VALVE 1 CWB051078
14 DISCHARGE MUFFLER (4 W.VALVE) 1 CWB121010
15 HOLDER COUPLING 1 CWH351233
16 2-WAYS VALVE (LIQUID) 1 ACXB02-02650 O
17 3-WAY VALVE (GAS) 1 CWB011581 O
19 REACTOR 1 G0C392J00028 O
20 TERMINAL COVER 1 CWH171039A
21 NUT - TERMINAL COVER 1 CWH7080300J
22 SOUND PROOF BOARD 1 CWH151428
23 SOUND PROOF MATERIAL 1 CWG302948
24 SENSOR CO - COMP TEMP 1 CWA50C2205 O
25 CONTROL BOARD COVER - TOP 1 ACXH13-00450
26 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C39660R O
27 TERMINAL BOARD ASSY 1 CWA28K1110J O
28 CABINET SIDE PLATE CO. 1 ACXE04C00460
29 SENSOR CO - AIR TEMP AND PIPE TEMP 1 CWA50C3079 O
30 CABINET SIDE PLATE (LEFT) 1 CWE041858A
31 CABINET FRONT PLATE CO. 1 CWE06C1566
32 CABINET TOP PLATE 1 CWE031230A
33 PLATE - C. B. COVER TERMINAL 1 CWH131301
34 CONTROL BOARD COVER CO. 1 CWH13C1359
36 SOUND PROOF MATERIAL 1 CWG302316
38 4-WAYS VALVE 1 ACXB00-00130 O
39 V-COIL COMPLETE (4-WAY VALVE) 1 ACXA43C00250 O
40 WIRE NET 1 ACXD04-00040A
41 BAG - COMPLETE 1 CWG87C900
42 V-COIL COMPLETE (EXP. VALVE) 1 ACXA43C00640 O
43 STRAINER 2 CWB111032
44 RECEIVER 1 CWB14011
46 PANASONIC BADGE 1 CWE373439
52 INSTALLATION INSTRUCTION 1 ACXF60-27460
53 INSTALLATION INSTRUCTION 1 ACXF60-27470
54 INSTALLATION INSTRUCTION 1 ACXF60-27480
55 INSTALLATION INSTRUCTION 1 ACXF60-27490
56 INSTALLATION INSTRUCTION 1 ACXF60-27500
To Next Page
