156
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-Z35UBEA REMARK
1 CHASSIS COMPLETE 1 CWD52K1277
2 SOUND PROOF MATERIAL (TOP) 1 CWG302719
3 FAN MOTOR BRACKET 1 CWD541167
4 SCREW - FAN MOTOR BRACKET 2 CWH551217
5 FAN MOTOR 1 L6CAYYYL0064 O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J
7 PROPELLER FAN ASSY 1 CWH03K1066
8 NUT - PROPELLER FAN 1 CWH56053J
9 COMPRESSOR 1 9RS102XFA21 O
10 ANTI - VIBRATION BUSHING 3 CWH50077
11 NUT - COMPRESSOR MOUNT 3 CWH561096
12 CONDENSER 1 CWB32C3547
13 EXPANSION VALVE 1 CWB051078
14 DISCHARGE MUFFLER (4 W.VALVE) 1 CWB121010
15 HOLDER COUPLING 1 CWH351233
16 2-WAYS VALVE (LIQUID) 1 ACXB02-02650 O
17 3-WAY VALVE (GAS) 1 CWB011581 O
19 REACTOR 1 G0C392J00028 O
20 TERMINAL COVER 1 CWH171039A
21 NUT - TERMINAL COVER 1 CWH7080300J
22 SOUND PROOF BOARD 1 ACXH15-01590
23 SOUND PROOF MATERIAL (BODY) 1 CWG302949
24 SENSOR CO - COMP TEMP 1 CWA50C2894 O
25 CONTROL BOARD COVER - TOP 1 CWH131473
26 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C39670R O
27 TERMINAL BOARD ASSY 1 CWA28K1110J O
28 CABINET SIDE PLATE CO. (RIGHT) 1 CWE04C1411
29 SENSOR CO - AIR TEMP AND PIPE TEMP 1 CWA50C3078 O
30 CABINET SIDE PLATE 1 CWE041579A
31 CABINET FRONT PLATE CO. 1 ACXE06C02830
32 CABINET TOP PLATE 1 CWE031148A
33 PLATE - C. B. COVER TERMINAL 1 CWH131470
34 CONTROL BOARD COVER CO. 1 CWH13C1253
38 4-WAYS VALVE 1 ACXB00-00130 O
39 V-COIL COMPLETE (4 WAY VALVE) 1 ACXA43C00250 O
40 WIRE NET 1 CWD041200A
41 V-COIL COMPLETE (EXP. VALVE) 1 ACXA43C00640 O
42 RECEIVER 1 CWB14011
43 STRAINER 2 CWB111032
44 PANASONIC BADGE 1 CWE373439
45 BAG - COMPLETE 1 CWG87C900
46 SOUND PROOF MATERIAL 1 CWG302701
49 INSTALLATION INSTRUCTION 1 ACXF60-27460
50 INSTALLATION INSTRUCTION 1 ACXF60-27470
51 INSTALLATION INSTRUCTION 1 ACXF60-27480
52 INSTALLATION INSTRUCTION 1 ACXF60-27490
53 INSTALLATION INSTRUCTION 1 ACXF60-27500
54 INSTALLATION INSTRUCTION 1 ACXF60-27510
55 INSTALLATION INSTRUCTION 1 ACXF60-27520
To Next Page
