Panasonic CS-Z25UFEAW Service Manual

159
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-Z50UBEA CU-Z60UBEA REMARK
1 CHASSIS COMPLETE 1 ACXD52K00320 ←
2 ANTI - VIBRATION BUSHING 3 CWH50077 ←
3 COMPRESSOR 1 9RD132XAA21 ← O
4 NUT - COMPRESSOR MOUNT 3 CWH561096 ←
5 SOUND PROOF MATERIAL 1 CWG302950 ←
6 FAN MOTOR BRACKET 1 ACXD54-00140 ←
7 FAN MOTOR 1 L6CAYYYL0076 ← O
8 SCREW - FAN MOTOR BRACKET 2 CWH551217 ←
9 SCREW - FAN MOTOR MOUNT 4 CWH551106J ←
10 PROPELLER FAN ASSY 1 ACXH03K00070 ←
11 NUT - PROPELLER FAN 1 CWH56053J ←
12 CONDENSER 1 ACXB32C08610 ←
14 EXPANSION VALVE 1 CWB051078 ←
15 4-WAYS VALVE 1 ACXB00-00140 ← O
18 HOLDER COUPLING 1 ACXH35-00080 ←
19 3-WAY VALVE (GAS) 1 ACXB01-00580 ← O
20 2-WAYS VALVE (LIQUID) 1 ACXB02-00210 ← O
22 SOUND PROOF BOARD 1 ACXH15-00200 ←
23 TERMINAL COVER 1 CWH171039A ←
24 NUT - TERMINAL COVER 1 CWH7080300J ←
25 SENSOR CO - COMP. TEMP. 1 CWA50C2185 ← O
27 V-COIL COMPLETE (4-WAY VALVE) 1 ACXA43C00250 ← O
28 V-COIL COMPLETE (EXP. VALVE) 1 ACXA43C00640 ← O
30 SENSOR - COMPLETE (AIR & PIPE TEMP.) 1 CWA50C3079 ←
31 REACTOR 1 G0C392J00027 G0C392J00029 O
33 TERMINAL BOARD ASSY 1 CWA28K1110J ← O
38 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C39680R ACXA73C39690R O
40 CONTROL BOARD COVER - TOP 1 ACXH13-00490 ←
41 CABINET SIDE PLATE (LEFT) 1 ACXE04-00580 ←
42 HANDLE 1 CWE161010 ←
43 CABINET SIDE PLATE (RIGHT) 1 ACXE04C00720 ←
45 CABINET FRONT PLATE CO. 1 ACXE06K00050 ←
46 WIRE NET 1 ACXD04-00130A ←
47 CABINET TOP PLATE 1 ACXE03-00170A ←
48 CONTROL BOARD COVER - COMPLETE 1 ACXH13C00170 ←
49 CONTROL BOARD COVER 1 CWH131470 ←
54 PANASONIC BADGE 1 CWE373439 ←
58 SOUND PROOF MATERIAL 1 CWG302636 ←
59 SOUND PROOF MATERIAL 1 CWG302630 ←
62 RECEIVER 1 CWB14011 ←
66 SOUND PROOF MATERIAL 1 CWG302632 ←
67 STRAINER 1 CWB11094 ←
68 BAG - COMPLETE 1 CWG87C900 ←
72 INSTALLATION INSTRUCTION 1 ACXF60-27460 ←
73 INSTALLATION INSTRUCTION 1 ACXF60-27470 ←
74 INSTALLATION INSTRUCTION 1 ACXF60-27480 ←
75 INSTALLATION INSTRUCTION 1 ACXF60-27490 ←
76 INSTALLATION INSTRUCTION 1 ACXF60-27500 ←
77 INSTALLATION INSTRUCTION 1 ACXF60-27510 ←
