Panasonic CS-Z35YKEA Service Manual

11
Model
Indoor CS-Z25YKEA
Outdoor CU-Z25YKEA
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (6-poles)
Output Power W 700
Indoor Fan
Type Cross-flow fan
Material ASG30
Motor Type DC (8-pole)
Input Power W 47.1
Output Power W 40
Speed
QLo
Cool rpm 500
Heat rpm 570
Lo
Cool rpm 610
Heat rpm 690
Me
Cool rpm 770
Heat rpm 890
Hi
Cool rpm 920
Heat rpm 1070
SHi
Cool rpm 980
Heat rpm 1130
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-pole)
Input Power W -
Output Power W 40
Speed Hi
Cool rpm 790
Heat rpm 790
Moisture Removal L/h (Pt/h) 1.5 (3.2)
Indoor Airflow
QLo
Cool m³/min (ft³/min) 5.30 (187)
Heat m³/min (ft³/min) 5.93 (209)
Lo
Cool m³/min (ft³/min) 6.56 (232)
Heat m³/min (ft³/min) 7.82 (276)
Me
Cool m³/min (ft³/min) 9.08 (321)
Heat m³/min (ft³/min) 10.97 (387)
Hi
Cool m³/min (ft³/min) 11.40 (400)
Heat m³/min (ft³/min) 13.80 (485)
SHi
Cool m³/min (ft³/min) 12.39 (437)
Heat m³/min (ft³/min) 14.75 (521)
Outdoor Airflow Hi
Cool m³/min (ft³/min) 27.60 (975)
Heat m³/min (ft³/min) 27.60 (975)
Refrigerant Cycle
Control Device Expansion Valve
Refrigerant Oil cm³ FW50S (320)
Refrigerant Type kg (oz) R32, 0.89 (31.4)
F-Gas
GWP 675
CO
2
eq (ton)
(Precharge Amount / Maximum Charged Amount)
0.60 / 0.69
