Panasonic CS-Z35YKEA Service Manual

171
19. Technical Data
Technical data provided are based on the air conditioner running under free frequency.
19.1 Cool Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Cool mode at 16°C Voltage: 230V
19.1.1 CS-Z25YKEA CU-Z25YKEA
Indoor (°C) Outdoor DB (°C)
DB WB
-25 -20
-10 -7 0 5
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19.0 2776 2412 389 2862 2450 381 2816 2724 411 3044 2626 371 3020 2667 398 2851 2627 357
22.0 3106 1882 387 3146 1867 376 3351 1896 344 3108 1940 412 3327 2060 337 3186 2015 382
23
15.7 2443 2268 429 2404 1811 435 2716 2599 417 2513 2469 414 2625 2543 381 2590 2519 387
18.4 2718 1793 377 2728 2277 388 2732 1937 417 2757 1937 408 2843 1966 404 2826 1986 404
20
13.3 2323 2290 387 2293 2265 382 2230 2188 367 2276 2237 434 2321 2276 435 2494 2442 376
15.8 2432 1717 439 2458 1766 429 2391 1823 448 2511 1882 401 2659 1951 380 2666 1966 391
Indoor (°C) Outdoor DB (°C)
DB WB
16 25
35
TC SHC IP TC SHC IP TC SHC IP
27
19.0 3041 2712 290 2955 2712 392 2500 2450 510
22.0 3418 2105 276 3226 1999 390 2857 1870 507
23
15.7 2784 2657 303 2617 2580 400 2351 2309 505
18.4 3139 2054 296 2885 1994 395 2498 1810 504
20
13.3 2618 2550 310 2391 2349 400 2163 2120 505
15.8 2880 2050 304 2614 1926 397 2327 1773 505
(Dry bulb value based on 46% humidity)
19.1.2 CS-Z35YKEA CU-Z35YKEA
Indoor (°C) Outdoor DB (°C)
DB WB
-25 -20
-10 -7 0 5
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19.0 3886 3022 649 4007 3069 635 3943 3414 685 4261 3290 618 4228 3342 663 3991 3292 596
22.0 4348 2359 645 4404 2340 627 4691 2376 573 4351 2431 686 4657 2581 562 4460 2524 636
23
15.7 3420 2842 716 3365 2270 725 3803 3257 696 3518 3190 690 3675 3186 635 3625 3156 646
18.4 3806 2247 629 3819 2853 646 3825 2427 695 3860 2426 679 3981 2463 673 3956 2488 674
20
13.3 3252 2870 644 3211 2838 636 3122 2964 612 3187 2998 724 3250 2986 724 3492 3138 626
15.8 3405 2151 732 3441 2213 715 3347 2284 747 3516 2358 668 3722 2445 633 3732 2464 651
Indoor (°C) Outdoor DB (°C)
DB WB
16 25
35
TC SHC IP TC SHC IP TC SHC IP
27
19.0 4257 3418 484 4137 3398 653 3500 3070 850
22.0 4786 2638 459 4516 2504 650 4000 2343 845
23
15.7 3898 3329 506 3663 3233 667 3291 3030 841
18.4 4395 2573 493 4038 2498 658 3498 2268 841
20
13.3 3665 3195 517 3347 3066 666 3028 2919 841
15.8 4032 2569 507 3660 2413 662 3258 2222 842
(Dry bulb value based on 46% humidity)
