11.2 Outdoor Unit
11.2.1 Main Printed Circuit Board
CN-TANK
CN-STM1
CN-MTR2
CN-HOT
CN-TH1
POWER
TRANSISTOR
(IPM)
AC-BLU
DATA
AC-BRW
