9.2 Outdoor Unit
9.2.1 CU-Z25YKEA CU-Z35YKEA CU-Z42YKEA
Resistance of Compressor Windings
MODEL
CU-Z25YKEA / CU-Z35YKEA /
CU-Z42YKEA
CONNECTION 9RS102XRA21 (Ω)
U-V 2.389
U-W 2.389
V-W 2.389
Note: Resistance at 20°C of ambient temperature.
FUSE 4 FUSE 5
FUSE 3
IC19
28
1
2
11
FUSE 2
FUSE 1
BLK
BLU
BRW
(BLK)
AC-BRW
(BRW)
AC-BLU
(BLU)
SOUND PROOF
BOARD
CN-STM1
(WHT)
