Panasonic CS-Z35YKEA Service Manual

23
Model
Indoor CS-Z71YKEA
Outdoor CU-Z71YKEA
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (6-pole)
Output Power W 1.50k
Indoor Fan
Type Cross-flow fan
Material ASG30
Motor Type DC (8-pole)
Input Power W 80.2
Output Power W 40
Speed
QLo
Cool rpm 830
Heat rpm 840
Lo
Cool rpm 930
Heat rpm 920
Me
Cool rpm 1070
Heat rpm 1080
Hi
Cool rpm 1200
Heat rpm 1250
SHi
Cool rpm 1250
Heat rpm 1330
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-pole)
Input Power W -
Output Power W 40
Speed Hi
Cool rpm 820
Heat rpm 840
Moisture Removal L/h (Pt/h) 4.1 (8.7)
Indoor Airflow
QLo
Cool m³/min (ft³/min) 12.35 (436)
Heat m³/min (ft³/min) 12.53 (442)
Lo
Cool m³/min (ft³/min) 14.15 (500)
Heat m³/min (ft³/min) 13.97 (493)
Me
Cool m³/min (ft³/min) 16.66 (588)
Heat m³/min (ft³/min) 16.84 (595)
Hi
Cool m³/min (ft³/min) 19.00 (670)
Heat m³/min (ft³/min) 19.90 (700)
SHi
Cool m³/min (ft³/min) 19.90 (703)
Heat m³/min (ft³/min) 21.34 (754)
Outdoor Airflow Hi
Cool m³/min (ft³/min) 44.7 (1580)
Heat m³/min (ft³/min) 45.8 (1615)
Refrigerant
Cycle
Control Device Expansion Valve
Refrigerant Oil cm³ FW50S (600)
Refrigerant Type kg (oz) R32, 1.35 (47.7)
F-Gas
GWP 675
CO
2
eq (ton)
(Precharge Amount / Maximum Charged Amount)
0.91 / 1.25
