Panasonic CS-Z35YKEA Service Manual

38
6.1.2 CS-Z50YKEA CS-Z71YKEA
12:00,Mon
SET TEMP.
FAN SPEED
25.0
FLAP
AUTO
AUTO
MODE
AUTO
15
<Remote Control Holder>
120
120
<Remote Control>
1040
41-61
360
244
295
<Top View>
<Front View>
<Bottom View>
<Rear View>
<Side View> <Side View>
Air outlet
direction
Air intake
direction
Right piping
hole
Left piping
hole
Gas side
Liquid side
PIPE HOLE
CENTER
210 mm
TO H OLE
CENTER
PIPE HOLE
CENTER
150 mm
TO HO LE
CENTER
150 mm
210 mm
210
276 247
150
537
748.4
503
278
226
Right
piping
hole
Left
piping
hole
Installation
plate
Indoor unit
external
dimensions
line
Unit: mm
14.9
270
Relative position between the indoor unit and the installation plate <Front View>
