Panasonic CT-2511HDB

- 10 -
Identification of Components
Figure 4. Rear View.
T551 (FLYBACK)
TRC (4 SCREWS)
ANODE (HIGH VOLTAGE)
Note: Following the service, remember to
dress the cables, as shown above.
DI-BOARD A-BOARD
DEFLECTION
YOKE
TUNER
DAG
GROUND
SPEAKERS
(4 SCREWS
EACH)
C-BOARD
YOKE
POSITION
WEDGE
CONVERGENCE
YOKE
