Panasonic CT-2511HDB

- 12 -
Location of Components
No LOCATION OF COMPONENTS
ICs 7 IC803 12 SPEAKERS. 17 TUNER
1 IC001 MPU 8 IC2301 AUDIO OUT 13 Q551 HOR. 18 D554
2IC002 9 IC2302AUDIO OUR 14 Q501 19 C552
3 IC101 VCJ 10 IC2451 SOUND AGC OTHERS 20 C809
4 IC451VERTICAL CONNECTORS 15 T551 (FLYBACK) 21 REMOTE SENSOR
5IC551 11 A/V INPUT (FRONT). 16 FUSE 22 RL801
6IC552
C-BOARD
DI-BOARD
(Except CT-2511H)
Z-BOARD(Except CT-2511H)
Figure 6. View of Boards.
Note: A/V Inputs not available on some models
A-BOARD
1
2
3
4
6
5
8 9 10
11
13
14
15
1617
18
19
20
2122 7
12
