Panasonic CT-2511HDB

- 39 -
Parts List
REPLACEMENT PARTS LIST
Models: CT-2511HDB, CT-2521HDB, CT-2721HDB, CT-3221HDB.
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
259-00
PARTS LIST
R2306 ERJ6GEYJ682 RES,M 6.8K-J-1/10
R2311 ERJ6GEYJ332 RES,M 3.3K-J-1/10
R2312 ERJ6GEYJ682 RES,M 6.8K-J-1/10
R2313 ERJ6GEYJ683 RES,M 68K-J-1/10
R2314 ERJ6GEYJ104 RES,M 100K-J-1/10
R2317 ERJ6GEYJ561 RES,M 560-J-1/10
R2318 ERJ6GEYJ103 RES,M 10K-J-1/10
R2319 ERDS2TJ562 RES,C 5.6K-J-1/4
R2321 ERDS2TJ101 RES,C 100-J-1/4
R2322 ERJ6GEYJ472 RES,M 4.7K-J-1/10
R2353 ERD25FJ1R0 RES,C 1.0-J-1/4
R2356 ERJ6GEYJ682 RES,M 6.8K-J-1/10
R2451 ERJ6GEYJ225 RES,M 2.2MEG-J-1/10
R2455 ERJ6GEYJ153 RES,M 15K-J-1/10
R2456 ERJ6GEYJ103 RES,M 10K-J-1/10
R3005 ERDS2TJ750 RES,C 75-J-1/4
R3006 ERDS2TJ391 RES,C 390-J-1/4
R3009 ERDS2TJ682 RES,C 6.8K-J-1/4
R3010 ERJ6GEYJ334 RES,M 330K-J-1/10
R3011 ERDS2TJ682
RES,C 6.8K-J-1/4 CT-2521HDB
CT-2721HDB CT-3221HDB
R3013 ERDS2TJ682
RES,C 6.8K-J-1/4 CT-2521HDB
CT-2721HDB CT-3221HDB
R3015 ERJ6GEYJ151
RES,M 150-J-1/10
CT-2721HDB CT-3221HDB
SWITCHES
S001 EVQPF106K SWITCH
S002 EVQPF106K SWITCH
S003 EVQPF106K SWITCH
S004 EVQPF106K SWITCH
S005 EVQPF106K SWITCH
S008 EVQPF106K SWITCH
S009 EVQPF106K SWITCH
TRANSFORMERS
T001 TLP16297
TRANSFORMER, POWER
SUPPLY
T501 TLH15452
TRANSFORMER, HORIZONTAL
DRIVER
REF NO. PART NO. DESCRIPTION
T502 ETE19Z30AY
TRANSFORMER, HORIZONTAL
COUPLING
T551 KFT4AB143F
TRANSFORMER, FLYBACK
CT-2511HDB
CT-2521HDB, CT-2721HDB
T551 KFT5AB106F TRANSFORMER CT-3221HDB
T751 ETE19Z30BY TRANSFORMER CT-3221HDB
T801 ETS28AE219NC
TRANSFORMER CT-2511HDB
CT-2521HDB CT-2721HDB
T801 ETS29AK2R6NC TRANSFORMER CT-3221HDB
CRYSTALS/FILTERS
X001 TSSA010 CRYSTAL
X101 M1969M SAW FILTER
X102 EFCS4R5MW5BA FILTER
X201 SFSH4R5MDB CRYSTAL
X501 TAFCSB503F38 CRYSTAL, CLOCK
X601 TSS2AA001 CRYSTAL, 3.58MHZ
OTHERS
M001 A63QDB891X
CRT 25”
CT-2511HDB CT-2521HDB
M002 EAS12D123JD3
SPEAKER 16 OHM, 3W
CT-2721HDB
TNR001 ENV56D37G3R TUNER
M003 ETC33X82NA YOKE, CONVERGENCE
M004 M68LGL061X CRT 27” CT-2721HDB
M005 M80JUA061X CRT 32” CT-3221HDB
M006 TAS2AA0005
SPEAKER 16-OHM 1.5W
CT-3221HDB
M007 TAS2AA0012
SPEAKER 16-OHM 1.5W
CT-2511HDB CT-2521HDB
M008 TBM2AA0021
BADGE, PANASONIC
CT-3221HDB
M009 TBM2A10141
BADGE, PANASONIC
CT-2511HDB
CT-2521HDB CT-2721HDB
M010 TXFBX02BSER
ASSY, 7-KEY BUTTON
CT-2511HDB CT-2521HDB
M011 TXFBX05BSER
ASSY, 7-KEY BUTTON
CT-2721HDB CT-3221HDB
M012 TJSC00300 CRT SOCKET
M013 TKU2AC0513S
ASSY, CABINET BACK
CT-2721HDB
