19.1.3 Three Indoor Unit Operation
 Cooling Characteristic
[Condition] Room temperature: 27°C (DBT), 19°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
A) Indoor unit capacity: Cooling (2.0 + 2.5 + 4.2), CS-TZ20TKEW + CS-TZ25TKEW + CS-TZ42TKEW
Indoor Discharge Air
Temperature (°C)
Outdoor Air Temperature (°C)
TZ20TKEW TZ42TKEWTZ25TKEW
14.100
14.700
15.300
15.900
16.500
17.100
17.700
18.300
18.900
19.500
20.100
-10-6 -2 2 6 10141822263034384246
Outdoor Air Temperature (°C)
Current
(A)
4.400
5.400
6.400
7.400
8.400
9.400
-10-6 -2 2 6 10141822263034384246
Gas Side Piping
Pressure (MPa)
Outdoor Air Temperature (°C)
1.100
1.119
1.138
1.157
1.176
1.195
1.214
1.233
1.252
1.271
1.290
-10 -6 -2 2 6 1014 1822 2630 3438 4246
